16 324D FM Forest Machine specifications
Hydraulic System
Main Implement System – 220 L/min 58.1 gal/min
Maximum Flow (2x)
Max. pressure – Implements 35 000 kPa 5,075 psi
Max. pressure – Travel 35 000 kPa 5,075 psi
Max. pressure – Swing 24 500 kPa 3,553 psi
Pilot System – Maximum flow 36 L/min 9.5 gal/min
Pilot System – Maximum pressure 3920 kPa 568 psi
Boom Cylinder – Bore 135 mm 5.3 in
Boom Cylinder – Stroke 1305 mm 51.4 in
Stick Cylinder – Bore 140 mm 5.5 in
Stick Cylinder – Stroke 1660 mm 65.4 in
Log Loader Linkage
Boom Cylinder – Bore 140 mm 5.5 in
Boom Cylinder – Stroke 1185 mm 46.7 in
Stick Cylinder – Bore 170 mm 6.7 in
Stick Cylinder – Stroke 1680 mm 66.1 in
Under/Under Heel Cylinder – Bore 130 mm 5.1 in
Under/Under Heel Cylinder – Stroke 1156 mm 45.5 in
Over/Under Heel Cylinder – Bore 150 mm 5.9 in
Over/Under Heel Cylinder – Stroke 1470 mm 57.9 in
Swing Mechanism
Swing Torque – General Forestry 73.4 kN·m 54,147 lb ft
Swing Speed – General Forestry 10 rpm
Excavator Linkage
CB1 Family Bucket Cylinder – Bore 130 mm 5.1 in
CB1 Family Bucket Cylinder – Stroke 1156 mm 45.5 in
Standards
Brakes SAE J1026 APR90
Cab/FOGS/OPS/TOPS/FOPS SAE J1356 FEB88 ISO 10262/
SAE J1084/ISO 8084/
OR-OSHA 437-007-0775/
WCB G602, G603, G604,
G608
Engine
Engine Model Cat ® C7 ACERT™
Net Flywheel Power 140 kW 188 hp
ISO 9249 140 kW 188 hp
J1349 139 kW 186 hp
EEC 80/1269 140 kW 188 hp
Bore 110 mm 4.3 in
Stroke 127 mm 5 in
Displacement 7.2 L 440 in 3
• The 324D FM meets U.S. EPA Tier 3 and EU Stage IIIa
emissions requirements.
• Net power advertised is the power available at the flywheel
when the engine is equipped with fan, air cleaner, muffler,
and alternator.
• No engine derating required below 2300 m (7500 ft) altitude.
Weights
General Forestry (HW) 31 226 kg 68,853 lb
Log Loader (U/U) 34 300 kg 75,698 lb
Log Loader (O/U) 34 484 kg 76,037 lb
• Operating weight with front linkage, without bucket or grapple.
Service Refill Capacities
Fuel Tank 520 L 137.4 gal
Fuel Tank – Optional Auxiliary 410 L 108.3 gal
Right Front
Optional Counterweight with 490 L 129.5 gal
Fuel Tank
Maximum Fuel with all 1420 L 375.2 gal
Optional Tanks
Cooling System 30 L 7.9 gal
Engine Oil 34 L 9 gal
Swing Drive 8 L 2.1 gal
Hydraulic System (including tank) 245 L 64.7 gal
Hydraulic Tank 145 L 38 gal
Final Drive (each) 8 L 2 gal
Drive
Maximum Travel Speed 5.7 km/h 3.5 mph
Maximum Drawbar Pull 259 kN 58,226 lb
