Dimensions
(approximate)
3
6
9
8
1 7
4
2 5
Tractor Dimensions
XL LGP XL Fine Grading
1 Trackgauge 1890mm 74.4in 2160mm 85in 1890mm 74.4in
2 Widthoftractor
Withthefollowingattachments:
Standardshoeswithoutblade 2500mm 98.4in 3000mm 118in 2500mm 98.4in
Narrowshoeswithoutblade 2450mm 96.5in 2870mm 113in 2450mm 96.5in
StandardshoeswithVPATbladefullyangled 3015mm 118.7in 3768mm 148.3in 3015mm 118.7in
StandardshoeswithVPATbladefoldable 2545mm 100in 3000mm 118in 2545mm 100in
3 Machineheightfromtipofgrouser:
Withthefollowingequipment:
Exhauststack 2979mm 117.3in 3083mm 121.4in 3083mm 121.4in
ROPScab 3088mm 121.57in 3190mm 125.6in 3202mm 126in
Fromgroundfaceofshoe 394mm 15.5in 507mm 20in 507mm 20in
4 Lengthoftrackonground 2611mm 102.8in 3113mm 122.56in 3206mm 126in
5 Lengthofbasictractor(withdrawbar) 3805mm 149.8in 4146mm 163.2in 4400mm 173in
Withthefollowingattachments,addtobasictractorlength:
Ripper(withtipatgroundline) 1026mm 40.4in 1026mm 40.4in 1026mm 40.4in
PA55winch 381mm 15in 381mm 15in 381mm 15in
VPATblades,straight 1343mm 52.8in 1705mm 67.1in 1705mm 67.1in
VPATblade,angled25° 1965mm 77.3in 2487mm 87.9in 2487mm 87.9in
SUblade 1417mm 55.8in — —
6 Heightoverstackfromtipofgrouser 2979mm 117.3in 3083mm 121.4in 3093mm 122in
7 Heightofgrouser 66mm 2.6in 57mm 2.2in 57mm 2.2in
8 Groundclearancefromgroundfaceofshoe(perSAEJ1234) 394mm 15.5in 507mm 20.0in 508mm 20in
9 Drawbarheight(grousertiptocenterofclevis)
Fromgroundfaceofshoe 595mm 22.2in 710mm 28in 709mm 28in
