D6N Track-Type Tractor Specifications
Blades Winch Sound Information and Vibration
Information
BladeType VPAT,SU WinchModel PA55
XLVPAT– 3.18m 3 4.16yd 3
BladeCapacity
LGPVPAT– 3.16m 3 4.13yd 3
BladeCapacity
LGPFoldable 3.16m 3 4.13yd 3
Blade Capacity
XLSU– 4.28m 3 5.6yd 3
BladeCapacity
XLVPAT– 3272mm 10ft9in
BladeWidth
LGPVPAT– 4080mm 13ft5in
BladeWidth
XLFoldable 4080mm 13ft5in
Blade Width
OilCapacity 74L 19.55gal
WinchandBracket 1145mm 45.1in
Length
WinchCaseWidth 975mm 38.4in
DrumDiameter 254mm 10in
DrumWidth 315mm 12.4in
FlangeDiameter 504mm 19.8in
DrumCapacity– 88m 288ft9in
22mm(0.88in)
WinchDrive Mechanical
Control Electric
Sound Level Information
•ThedeclaredoperatorEquivalentSound
PressureLevel(Leq)is83dB(A)when
“ANSI/SAEJ1166FEB2008”isused
to measurethevalueforanenclosedcab.
The measurementwasconductedat100%
ofthemaximumenginecoolingfanspeed.
Thisisaworkcyclesoundexposurelevel.
Thecabwasproperlyinstalledand
maintained.The testwasconductedwith
thecabdoorsandthecabwindowsclosed.
•Hearingprotectionmaybeneededwhen
themachineisoperatedwithanopen
operatorstationforextendedperiodsor
in anoisyenvironment.Hearingprotection
maybeneededwhenthemachineisoperated
withacabthatisnotproperlymaintained,
orwhenthedoorsandwindowsareopenfor
extendedperiodsorinanoisyenvironment.
•Thedeclaredaverageexteriorsoundpressure
levelis83dB(A)whenthe“SAE J88
FEB2006–ConstantSpeedMovingTest”
procedureisusedtomeasurethevaluefor
thestandardmachine.Themeasurement
wasconductedunderthefollowing
conditions:distanceof15m(49.2 ft)
and “themachinemovingforward
in an intermediategearratio.”
Sound Level Information for Machines
in European Union Countries and in
Countries that Adopt the “EU Directives”
Theinformationbelowappliestoonlythe
machineconfigurationsthathavethe“CE”
markontheProductIdentificationPlate.
•Thedeclareddynamicoperatorsound
pressurelevelis78dB(A)when
“ISO 6396:2008”isusedtomeasurethe
valueforanenclosedcab.Themeasurement
wasconductedat100%ofthemaximum
enginecoolingfanspeed.Thesoundlevel
mayvaryatdifferentenginecoolingfan
speeds.Thecabwasproperlyinstalled
and maintained.Themeasurementwas
conductedwiththecabdoorsandthe
cab windowsclosed.
•Ifequipped,thecertificationlabel –
110 dB(A)–isusedtoverifythe
environmentalsoundcertificationof
the machinetotherequirementsofthe
EuropeanUnion.Thevaluethatislisted
onthelabelindicatestheguaranteed
exteriorsoundpowerlevel(Lwa)atthetime
ofmanufacturefortheconditionsthatare
specifiedin“2000/14/EC.”Yourmachine
mayhaveadifferentvalue.
XLSU– 3154mm 10ft4in
BladeWidth
XLSU–Narrow* 3000mm 9ft10in
Bladewidth
*ForEuropeonly;Widthiswithendbits
removed;Bladewidthwithendbitsis
3126 mm(10ft).
Ripper
Type FixedParallelogram
PocketSpacing 1000mm 3ft3.4in
ShankGauge 2m 6ft7in
ShankSection 73mm×176 mm
2.9in×6.9in
NumberofPockets 3
OverallBeamWidth 2202mm 86.7in
BeamCrossSection 216mm×254mm
8.5in×10.0in
MaximumClearance, 622mm 24.5in
Raised(ShankTip)
Maximum 51.6kN 11,600lbf
PenetrationForce
–XL
MaximumPry-out 211.2kN 47,480lbf
Force–XL
Maximum
PenetrationForce
– LGP 43kN 9,667lbf
MaximumPry-out 170kN 38,217lbf
Force–LGP
NumberofPockets 3
inRipperBeam
Maximum 514mm 20.2in
Penetration–XL
Maximum 398mm 15.6in
Penetration–LGP
EachAdditional 78kg 172lb
Shank
Weight: 1562kg 3,444lb
with 3 Shanks
16
OverallWidth 975mm 38.4in
RopeDiameter 19mm 0.75in
(recommended)
CableFerruleSize 54mm× 2.13in×
(O.D.×Length) 67mm 2.63in
MaximumBareDrum
LinePull 31388.5kg 69,200lb
LineSpeed 44.8m/min 147ft/min
MaximumFullDrum
LinePull 23539kg 54,100lb
LineSpeed 78.3m/min 257ft/min
•Slowandstandardspeedwinchesare
available.
Standards
ROPS/FOPS ROPS(RolloverProtective
Structure)offeredby
Caterpillarforthemachine
meetsROPScriteria
SAE J1040-1994,
ISO 3471:2008andDLV
criteriaSAEJ397B-2009,
ISO 3164:1995.
FOPS(FallingObject
ProtectiveStructure)meets
ISO 3449-2005LevelII
andDLVcriteria
SAE J397B-2009,
ISO 3164:1995.
Brakes Brakesmeetthestandard
ISO10265:2008and
ISO 3449:2008
Cab Meetsappropriate
standardsaslistedin
the followingsection
