17
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities
R3.0 STICK – 3.0 m (9'10")
BUCKET – 0.52 m
3 (0.68 yd 3 )
UNDERCARRIAGE – Long
SHOES – 700 mm (28") triple grouser BOOM – Reach 4.65 m (15.25 ft)
BLADE – Up
* Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity
standard SAE J1097 DEC2005. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted
from the above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
7.5 m kg *1400 *1400 5.86
25.0 ft lb *3,100 *3,100 18.73
6.0 m kg *2250 *2250 *1200 *1200 7.22
20.0 ft lb *4,450 *4,450 *2,650 *2,650 23.47
4.5 m kg *2600 2450 *1150 *1150 8.00
15.0 ft lb *5,750 5,200 *2,500 *2,500 26.14
3.0 m kg *3300 *3300 *2950 2350 *1850 1500 *1150 *1150 8.38
10.0 ft lb *7,150 *7,150 *6,450 5,000 *2,550 *2,550 27.47
1.5 m kg *6750 6550 *4400 3550 3400 2250 2350 1500 *1250 1250 8.43
5.0 ft lb *14,500 14,350 *9,500 7,550 7,300 4,750 *4,750 3,200 *2,750 2,700 27.67
Ground kg *8200 6100 5200 3300 3300 2100 2300 1450 *1400 1300 8.17
Line lb *18,550 13,050 11,500 7,050 7,050 4,500 *4,050 3,100 *3,100 2,800 26.80
–1.5 m kg *4000 *4000 *8350 5900 5050 3150 3200 2050 *1700 1450 7.55
–5.0 ft lb *8,950 *8,950 *18,700 12,650 10,850 6,750 6,850 4,400 *3,750 3,200 24.74
–3.0 m kg *6550 *6550 *8500 5950 5050 3150 3200 2050 *2300 1900 6.47
–10.0 ft lb *14,700 *14,700 *18,350 12,700 10,800 6,700 6,900 4,400 *5,050 4,150 21.08
–4.5 m kg *6750 6150 *4350 3250 *3700 2850 4.95
–15.0 ft lb *14,350 13,150 *9,050 7,000 *8,100 6,450 15.93
R3.0 STICK – 3.0 m (9'10")
BUCKET – 0.52 m
3 (0.68 yd 3 )
UNDERCARRIAGE – Long
SHOES – 600 mm (24") triple grouser BOOM – Reach 4.65 m (15.25 ft)
BLADE – Up
* Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity
standard SAE J1097 DEC2005. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted
from the above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
7.5 m kg *1400 *1400 5.86
25.0 ft lb *3,100 *3,100 18.73
6.0 m kg *2250 *2250 *1200 *1200 7.22
20.0 ft lb *4,450 *4,450 *2,650 *2,650 23.47
4.5 m kg *2600 2400 *1150 *1150 8.00
15.0 ft lb *5,750 5,100 *2,500 *2,500 26.14
3.0 m kg *3300 *3300 *2950 2300 *1850 1500 *1150 *1150 8.38
10.0 ft lb *7,150 *7,150 *6,450 4,950 *2,550 *2,550 27.47
1.5 m kg *6750 6550 *4400 3450 3350 2200 2300 1500 *1250 1200 8.43
5.0 ft lb *14,500 14,100 *9,500 7,400 7,150 4,650 *4,750 3,150 *2,750 2,600 27.67
Ground kg *8200 5950 5100 3200 3200 2050 2250 1450 *1400 1250 8.17
Line lb *18,550 12,800 10,950 6,900 6,900 4,400 *4,050 3,050 *3,100 2,700 26.80
–1.5 m kg *4000 *4000 *8350 5800 4950 3100 3150 2000 *1700 1400 7.55
–5.0 ft lb *8,950 *8,950 *18,700 12,400 10,600 6,600 6,700 4,300 *3,750 3,100 24.74
–3.0 m kg *6550 *6550 *8500 5800 4950 3050 3150 2000 *2300 1850 6.47
–10.0 ft lb *14,700 *14,700 *18,350 12,450 10,600 6,600 6,750 4,300 *5,050 4,100 21.08
–4.5 m kg *6750 6000 *4350 3200 *3700 2800 4.95
–15.0 ft lb *14,350 12,900 *9,050 6,850 *8,100 6,300 15.93
