7
SystemOne™ Undercarriage
Lower owning and operating costs.
SystemOne™ Undercarriage
Exclusively for Caterpillar machines, the design extends system life and reduces operating costs.
Undercarriage Arrangements
XL (Extra Long) arrangement
Forward idler position provides more track on the ground and to the front of the tractor. •
It provides optimal balance, superior traction and blade control for finish grading.
Long roller frame provides good flotation in soft underfoot conditions.
•
LGP (Low Ground Pressure) arrangement
Specially designed to work in soft and spongy conditions. •
Wide track shoes, a longer track frame and a wider gauge increase track contact area and reduce •
ground pressure for excellent flotation.
Equalizer Bar
The pinned equalizer bar gives the roller frames the ability to oscillate up or down to better match
ground contours while providing maximum traction and operator comfort.
