12
D6N Track-Type Tractor Specifications
Ripper
Type Fixed Parallelogram
Number of Pockets 3
Overall Beam Width 2202 mm 86.7 in
Beam Cross Section 216 × 254 mm
8.5 × 10.0 in
Maximum
Penetration – XL 473.5 mm 18.6 in
Maximum
Penetration – LGP 359.5 mm 14.2 in
Each Additional
Shank 78 kg 172 lb
Winch
Winch Model PA55
Weight* 1276.5 kg 2,814 lb
Oil Capacity 74 L 19.55 gal
Winch and Bracket
Length 1145 mm 45.1 in
Winch Case Width 975 mm 38.4 in
Drum Diameter 254 mm 10 in
Drum Width 315 mm 12.4 in
Flange Diameter 504 mm 19.8 in
Drum Capacity –
22 mm (0.88 in) 88 m 288 ft 9 in
Slow and standard speed winches are •
available.
* Weight: Includes pump, operator controls,
oil, mounting brackets and spacers.
Standards
ROPS/FOPS
Brakes
Cab
ROPS (Rollover Protective Structure) •
offered by Caterpillar for the machine
meets ROPS criteria SAE J1040 MAY94,
ISO 3471:1994 and DLV criteria
SAE J397B, ISO 3164:1995.
FOPS (Falling Object Protective Structure)
•
meets SAE J/ISO 3449 APR98 Level II,
ISO 3449:1992 Level II and DLV criteria
SAE J397B, ISO 3164:1995.
Brakes meet the standard ISO 10265:1998.
•
The operator sound exposure Leq •
(equivalent sound pressure level) measured
according to the work cycle procedures
specified in ANSI/SAE J1166 OCT 98 is
83 dB(A), for cab offered by Caterpillar,
when properly installed and maintained and
tested with the doors and windows closed.
The operator sound pressure level measured
•
according to the procedures specified in
ISO6394:2008 is 77 dB(A) for the cab
offered by Caterpillar, when properly
installed and maintained and tested with
the doors and windows closed.
Hearing protection is recommended when
•
operating with an open operator station
and cab (when not properly maintained or
doors/windows open) for extended periods
or in noisy environment.
The exterior sound pressure level for the
•
standard machine measured at a distance of
15 meters according to the test procedures
specified in SAE J88 FEB 06, mid-gear-
moving operation, is 81 dB(A).
The labeled sound power level is 110 dB(A)
•
measured according to the test procedure
and conditions specified in 2000/14/EC.
