22 321D LCR Hydraulic Excavator specifications
STICK – 2.5 m (8'3")
BUCKET – 0.82 m
3 (1.07 yd 3 )
UNDERCARRIAGE – Long
SHOES – 800 mm (32") triple grouser BOOM – 5.7 m (18'9")
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
9.0 m kg *2700 *2700 5.75
30.0 ft lb *6,100 *6,100 18.13
7.5 m kg *5100 *5100 *3800 *3800 *2350 *2350 7.44
25.0 ft lb *10,700 *10,700 *7,650 *7,650 *5,250 *5,250 24.08
6.0 m kg *5800 *5800 *5450 4750 *2250 *2250 8.42
20.0 ft lb *12,550 *12,550 *11,950 10,100 *4,950 *4,950 27.48
4.5 m kg *9750 *9750 *7200 *7200 *6100 4600 5250 3050 *2250 2200 8.98
15.0 ft lb *20,650 *20,650 *15,500 *15,500 *13,200 9,850 *10,550 6,500 *4,950 4,850 29.42
3.0 m kg *9200 6900 *7000 4350 5150 2950 *2350 2050 9.22
10.0 ft lb *19,750 14,850 *15,100 9,350 11,050 6,300 *5,200 4,450 30.23
1.5 m kg *10 850 6350 7250 4100 5050 2850 *2550 2000 9.16
5.0 ft lb *23,350 13,700 15,550 8,800 10,800 6,100 *5,600 4,400 30.05
Ground kg *6450 *6450 11 400 6100 7050 3950 4950 2800 *2900 2150 8.79
Line lb *14,800 *14,800 24,400 13,100 15,150 8,450 10,600 5,950 *6,350 4,650 28.85
–1.5 m kg *7050 *7050 *11 400 *11 400 *11 300 6050 7000 3900 4950 2750 *3450 2450 8.09
–5.0 ft lb *15,750 *15,750 *25,850 25,650 24,250 12,950 15,000 8,350 *7,600 5,450 26.48
–3.0 m kg *12 100 *12 100 *14 150 12 300 *10 100 6150 7050 3950 *4500 3300 6.91
–10.0 ft lb *27,100 *27,100 *30,600 26,300 *21,800 13,200 15,150 8,500 *9,850 7,300 22.53
–4.5 m kg *10 400 *10 400 *7400 6450 *5900 5100 5.24
–15.0 ft lb *22,100 *22,100 *15,550 13,850 *12,900 11,600 16.88
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
9.0 m kg *4600 *4600 4.37
30.0 ft lb *10,400 *10,400 13.51
7.5 m kg *5650 *5650 *4650 *4650 *3800 *3800 6.19
25.0 ft lb *12,500 *12,500 *8,450 *8,450 19.95
6.0 m kg *6150 *6150 *5850 5050 *3550 *3550 7.28
20.0 ft lb *13,350 *13,350 *12,850 10,850 *7,800 *7,800 23.70
4.5 m kg *10 050 *10 050 *7550 *7550 *6450 4900 5600 3400 *3500 3050 7.94
15.0 ft lb *21,350 *21,350 *16,300 *16,300 *14,050 10,550 *11,250 7,250 *7,700 6,800 25.97
3.0 m kg *9550 7200 *7400 4650 5500 3300 *3650 2800 8.28
10.0 ft lb *20,550 15,500 *15,950 10,050 11,750 7,050 *7,950 6,150 27.13
1.5 m kg *11 250 6700 7550 4450 5350 3200 *3900 2700 8.33
5.0 ft lb *24,250 14,450 16,250 9,550 11,500 6,850 *8,550 5,950 27.34
Ground kg *6850 *6850 11 750 6450 7400 4300 5300 3100 *4400 2800 8.11
Line lb *15,700 *15,700 25,150 13,900 15,850 9,200 11,350 6,700 *9,650 6,100 26.61
–1.5 m kg *7350 *7350 *11 850 *11 850 11 650 6400 7300 4200 5250 3100 5200 3050 7.59
–5.0 ft lb *16,450 *16,450 *26,850 26,650 25,000 13,750 15,700 9,050 11,400 6,700 24.86
–3.0 m kg *12 500 *12 500 *14 600 12 700 *10 550 6500 7350 4250 6300 3700 6.70
–10.0 ft lb *28,000 *28,000 *31,600 27,150 *22,700 13,900 15,850 9,200 13,950 8,200 21.85
–4.5 m kg *10 800 *10 800 *7800 6750 *6300 5400 5.24
–15.0 ft lb *23,000 *23,000 *16,400 14,500 *13,750 12,250 16.89
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities
STICK – 2.5 m (8'3")
BUCKET – No Bucket, Bare Quick Coupler UNDERCARRIAGE – Long
SHOES – 800 mm (32") triple grouser BOOM – 5.7 m (18'9")
HEAVY LIFT – On
Load at Maximum
Reach – Coupler Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
