20 325D FM Forest Machine specifications
325D FM LL-AEM-Cab Butt-N-Top Lift Capacities
CONFIGURATION – 11.3 m (37') Boom/Stick Linkage SHOES – 700 mm (28") Double Grouser
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side ft
10.5 m kg *14 400 *14 400 *12 250 *12 250 *11 500 8500 *11 050 8450 7.53
35.0 ft lb *31,650 *31,650 *27,000 26,600 *24,850 19,300 24.06
9.0 m kg *13 950 *13 950 *11 900 *11 900 *10 500 8800 9000 6500 8.93
30.0 ft lb *30,500 *30,500 *26,000 *26,000 *22,950 18,900 20,250 14,600 28.94
7.5 m kg *14 400 *14 400 *12,100 *12,100 *10 500 8800 9050 6600 7700 5550 9.92
25.0 ft lb *31,250 *31,250 *26,300 *26,300 *22,850 18,950 19,450 14,150 17,100 12,350 32.31
6.0 m kg *15 000 *15 000 *12 700 12 200 *10 750 8650 9050 6550 7050 5100 6950 5000 10.59
20.0 ft lb *33,550 *33,550 *27,550 26,300 *23,350 18,650 19,400 14,100 15,350 11,050 34.64
4.5 m kg *13 550 11 800 *11 100 8450 8900 6450 7050 5100 6500 4700 11.03
15.0 ft lb *29,350 25,350 *24,100 18,200 19,150 13,850 15,150 10,950 14,400 10,350 36.12
3.0 m kg *14 300 11 250 *11 400 8150 8750 6300 7000 5050 *6250 4550 11.24
10.0 ft lb *30,900 24,250 *24,650 17,600 18,850 13,550 15,050 10,850 *13,800 10,000 36.86
1.5 m kg *14 400 10 800 11 200 7900 8600 6150 6950 5000 *5500 4550 11.25
5.0 ft lb *31,150 23,250 24,100 17,050 18,550 13,250 14,900 10,700 *12,100 9,950 36.90
Ground kg *13 550 10 500 *10 650 7750 *8400 6050 *6200 4950 *4600 *4600 11.05
Line lb *29,350 22,550 *23,000 16,650 *18,100 13,050 *12,850 10,650 *10,100 *10,100 36.25
–1.5 m kg *9100 *9100 *11 650 10 350 *9250 7650 *7100 6000 *4300 *4300 10.47
–5.0 ft lb *21,150 *21,150 *25,250 22,300 *19,950 16,500 *15,100 13,000 *9,400 *9,400 34.30
–3.0 m kg *8800 *8800 *7000 *7000 *5200 *5200 8.78
–10.0 ft lb *18,850 *18,850 *14,850 *14,850 *11,600 *11,600 28.47
325D FM GF Reach Boom Lift Capacities
CONFIGURATION – 6.15 m (20'2") Boom, 3.2 m (10'6") Stick,
Heavy Counterweight
SHOES – 700 mm (28") Double Grouser
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side Front Side ft
7.5 m kg *5350 *5350 7.47
25.0 ft lb *11,850 *11,850 24.22
6.0 m kg *7550 *7550 *5150 *5150 8.35
20.0 ft lb *16,600 *16,600 *11,350 *11,350 27.26
4.5 m kg *9000 *9000 *8100 *8100 *5150 *5150 8.90
15.0 ft lb *19,500 *19,500 *17,600 *17,600 *11,350 *11,350 29.12
3.0 m kg *13 850 *13 850 *10 450 *10 450 *8800 8550 *6500 *6500 *5350 *5350 9.60
10.0 ft lb *29,750 *29,750 *22,550 *22,550 *19,100 18,400 *11,950 *11,950 *11,750 *11,750 30.04
1.5 m kg *16 150 *16 150 *11 700 11 300 *9500 8350 *7150 6550 *5700 *5700 9.17
5.0 ft lb *34,850 *34,850 *25,350 24,300 *20,650 18,000 *13,100 *13,100 *12,500 *12,500 30.10
Ground kg *6150 *6150 *17 100 16 650 *12 500 11 050 *9950 8200 *6300 *6300 8.93
Line lb *14,050 *14,050 *37,000 35,850 *27,100 23,800 *21,600 17,700 *13,850 *13,850 29.29
–1.5 m kg *7550 *7550 *11 250 *11 250 *16 900 16 600 *12 650 10 950 *10 000 8150 *7300 7050 8.41
–5.0 ft lb *16,850 *16,850 *25,400 *25,400 *36,600 35,700 *27,350 23,600 *21,550 17,600 *16,150 15,550 27.56
–3.0 m kg *12 650 *12 650 *17 750 *17 750 *15 700 *15 700 *11 900 11 000 *9050 8200 *8900 8150 7.56
–10.0 ft lb 28,400 28,400 *40,300 *40,300 *33,950 *33,950 *25,700 23,700 *19,650 18,050 24.69
–4.5 m kg *17 600 *17 600 *13 050 *13 050 *9550 *9550 *8950 *8950 6.24
–15.0 ft lb 37,800 37,800 *27,900 *27,900 *20,050 *20,050 *19,650 *19,650 20.20
