19 325D FM Forest Machine specifications
325D FM LL Heel Boom Under/Under Lift Capacities
CONFIGURATION – 12.2 m (40') Boom/Stick/Heel Linkage SHOES – 700 mm (28") Double Grouser
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side Front Side ft
10.5 m kg *10 550 *10 550 *9400 8450 *7850 6100 8.86
35.0 ft lb *23,150 *23,150 *20,650 18,000 *17,600 13,850 28.53
9.0 m kg *10 300 *10 300 *9150 8550 *8250 6200 *6950 4900 10.08
30.0 ft lb *22,500 *22,500 *20,000 18,350 *18,000 13,250 *15,500 11,000 32.73
7.5 m kg *10 500 *10 500 *9250 8550 *8200 6250 6650 4700 6100 4250 10.96
25.0 ft lb *22,850 *22,850 *20,100 18,300 *17,850 13,350 14,200 9,950 13,550 9,450 35.75
6.0 m kg *9900 *9900 *11 150 *11 150 *9550 8350 *8300 6150 6650 4700 5550 3850 11.57
20.0 ft lb *22,250 *22,250 *24,200 *24,200 *20,750 18,000 *18,050 13,200 14,250 10,000 12,300 8,500 37.86
4.5 m kg *12 100 11 600 *10 000 8100 8500 6000 6600 4650 5250 3600 11.97
15.0 ft lb *26,200 24,950 *21,700 17,400 18,250 12,900 14,150 9,900 11,550 7,950 39.22
3.0 m kg *13 100 11 000 *10 450 7750 8300 5850 6500 4550 5200 3600 *5050 3500 12.17
10.0 ft lb *28,300 23,650 *22,650 16,700 17,850 12,500 13,950 9,700 *11,100 7,700 39.90
1.5 m kg *13 650 10 400 *10 650 7450 8100 5650 6400 4450 *4950 3550 *4400 3500 12.17
5.0 ft lb *29,500 22,350 *23,050 16,000 17,400 12,100 13,700 9,500 *9,700 7,650 39.94
Ground kg *13 350 9950 *10 350 7150 7950 5500 6300 4350 *3650 3600 11.99
Line lb *28,950 21,350 *22,400 15,400 17,050 11,800 13,550 9,350 *8,050 7,850 39.34
–1.5 m kg *8250 *8250 *12 100 9650 *9450 7000 *7350 5400 *5350 4300 *3100 *3100 11.55
–5.0 ft lb *19,300 *19,300 *26,200 20,800 *20,300 15,050 *15,700 11,600 *11,150 9,250 *6,850 *6,850 37.84
–3.0 m kg *10 800 *10 800 *9900 9600 *7750 6950 *5750 5350 *3600 *3600 10.40
–10.0 ft lb *25,000 *25,000 *21,250 20,650 *16,500 14,950 *12,100 11,550 *7,900 *7,900 33.96
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 100% of hydraulic lifting capacity or 100% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
325D FM LL Heel Boom Over/Under Lift Capacities
CONFIGURATION – 12.8 m (42') Boom/Stick/Heel Linkage SHOES – 700 mm (28") Double Grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft
Load at
Load
Maximum Reach
Point Over Over Over Over Over Over Over Over Over Over Over Over Over Over Over Over m
Height Front Side Front Side Front Side Front Side Front Side Front Side Front Side Front Side ft
10.5 m kg *9900 *9900 *8900 8750 *8150 6250 *6800 5350 9.67
35.0 ft lb *21,750 *21,750 *19,600 18,650 *17,950 13,300 *15,150 12,100 31.22
9.0 m kg *9700 *9700 *8750 *8750 *7950 6450 6750 4750 *6100 4450 10.79
30.0 ft lb *21,200 *21,200 *19,100 *19,100 *17,350 13,700 14,250 10,000 *13,550 9,900 35.11
7.5 m kg *9900 *9900 *8850 8800 *7950 6450 6850 4850 5600 3900 11.62
25.0 ft lb *21,550 *21,550 *19,250 18,850 *17,300 13,750 14,600 10,300 12,400 8,650 37.93
6.0 m kg *10 550 *10 550 *9200 8600 *8100 6350 6800 4800 5350 3700 5150 3550 12.20
20.0 ft lb *22,900 *22,900 *19,950 18,500 *17,600 13,550 14,550 10,300 11,400 7,850 39.92
4.5 m kg *11 550 *11 550 *9700 8300 *8350 6150 6700 4750 5350 3700 4900 3350 12.58
15.0 ft lb *25,000 *25,000 *21,050 17,850 *18,050 13,200 14,350 10,100 11,400 7,900 10,750 7,400 41.21
3.0 m kg *12 650 11 300 *10 250 7950 8400 5950 6600 4600 5300 3650 *4750 3250 12.76
10.0 ft lb *27,350 24,250 *22,150 17,050 18,100 12,750 14,100 9,850 11,300 7,800 *10,450 7,150 41.86
1.5 m kg *13 450 10 600 *10 550 7550 8200 5700 6450 4500 5200 3600 *4150 3250 12.77
5.0 ft lb *29,050 22,750 *22,850 16,250 17,600 12,250 13,800 9,600 11,200 7,700 *9,150 7,100 41.90
Ground kg *13 500 10 000 *10 500 7200 7950 5500 6300 4350 *4900 3550 *3500 3300 12.60
Line lb *29,200 21,500 22,550 15,550 17,150 11,850 13,600 9,350 *10,100 7,600 *7,650 7,250 41.33
–1.5 m kg *8450 *8450 *12 650 9650 *9800 7000 *7750 5400 *5950 4300 *3600 3550 *2850 *2850 12.21
–5.0 ft lb *19,750 *19,750 *27,300 20,750 *21,150 15,050 *16,600 11,550 *12,550 9,250 *6,350 *6,350 *6,250 *6,250 40.02
–3.0 m kg *4800 *4800 *10 250 *10 250 *10 800 9500 *8450 6900 *6450 5300 *4500 4300 *3200 *3200 11.25
–10.0 ft lb *10,900 *10,900 *23,700 *23,700 *23,200 20,400 *18,050 14,800 *13,750 11,450 *9,200 *9,200 *7,050 *7,050 36.75
–4.5 m kg *7950 *7950 *6200 *6200 *4400 *4400 *4150 *4150 9.18
–15.0 ft lb *16,900 *16,900 *13,000 *13,000 *9,350 *9,350 29.53
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
Weight of all lifting accessories must be deducted from the above lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
