16 325D FM Forest Machine specifications
Hydraulic System
Main Implement System – 235 L/min 62.1 gal/min
Maximum Flow (2x)
Max. pressure – Implements 35 000 kPa 5,075 psi
Max. pressure – Travel 35 000 kPa 5,075 psi
Max. pressure – Swing 27 500 kPa 3,988 psi
Pilot System – Maximum flow 36 L/min 9.5 gal/min
Pilot System – Maximum pressure 4120 kPa 597 psi
Boom Cylinder – Bore 140 mm 5.5 in
Boom Cylinder – Stroke 1407 mm 55.4 in
Stick Cylinder – Bore 150 mm 5.9 in
Stick Cylinder – Stroke 1646 mm 64.8 in
Log Loader Linkage
Boom Cylinder – Bore 150 mm 5.9 in
Boom Cylinder – Stroke 1400 mm 55.1 in
Stick Cylinder – Bore 180 mm 7.1 in
Stick Cylinder – Stroke 1650 mm 65 in
Under/Under Heel Cylinder – Bore 150 mm 5.9 in
Under/Under Heel Cylinder – Stroke 1155 mm 45.5 in
Over/Under Heel Cylinder – Bore 160 mm 6.3 in
Over/Under Heel Cylinder – Stroke 1465 mm 57.7 in
Swing Mechanism
Swing Torque – General Forestry 86.3 kN·m 63,664 lb ft
Swing Speed – General Forestry 10 rpm
Excavator Linkage
CB2 Family Bucket Cylinder – Bore 135 mm 5.3 in
CB2 Family Bucket Cylinder – Stroke 1156 mm 45.5 in
Standards
Brakes SAE J1026 APR90
Cab/FOGS/OPS/TOPS/FOPS SAE J1356 FEB88 ISO 10262/
SAE J1084/ISO 8084/
OR-OSHA 437-007-0775/
WCB G602, G603, G604,
G608
Engine
Engine Model Cat ® C7 ACERT™
Net Flywheel Power 152 kW 204 hp
ISO 9249 152 kW 204 hp
J1349 152 kW 204 hp
EEC 80/1269 152 kW 204 hp
Bore 110 mm 4.3 in
Stroke 127 mm 5 in
Displacement 7.2 L 440 in 3
• The 325D FM meets U.S. EPA Tier 3 and EU Stage IIIa
emissions requirements.
• Net power advertised is the power available at the flywheel
when the engine is equipped with fan, air cleaner, muffler,
and alternator.
• No engine derating required below 2300 m (7,500 ft) altitude.
Weights
General Forestry (HW) 33 329 kg 73,478 lb
Log Loader (U/U) 37 807 kg 83,350 lb
Log Loader (O/U) 38 211 kg 84,241 lb
• Operating weight with front linkage, without bucket or grapple.
Service Refill Capacities
Fuel Tank 520 L 137.4 gal
Fuel Tank – Optional Auxiliary 410 L 108.3 gal
Right Front
Optional Counterweight 490 L 129.5 gal
with Fuel Tank
Maximum Fuel with 1420 L 375.2 gal
all Optional Tanks
Cooling System 30 L 7.9 gal
Engine Oil 34 L 9 gal
Swing Drive 10 L 2.6 gal
Hydraulic System (including tank) 260 L 68.7 gal
Hydraulic Tank 145 L 38 gal
Final Drive (each) 8 L 2 gal
Drive
Maximum Drawbar Pull 256 kN 57,551 lb
Maximum Travel Speed 5.5 km/h 3.4 mph
