336ELBucketSpecificationsandCompatibility
Linkage
Width
Capacity
Weight
Fill
MassBoom
HeavyDutyBoom
ExtremeServiceBoom
mm
in
m
3
yd
3
kg
lb
%
M2.55
(8'4")
R3.2HD
(10'6")
R3.9HD
(12'10")
R3.2ES
(10'6")
R3.9ES
(12'10")
WithCenter-LockQuickCoupler
GeneralDuty(GDC)
DB
750
30
0.94 1.23
952
2,099
100%
DB
900
36
1.19 1.56
1040
2,292
100%
DB
1050
42
1.46 1.91
1147
2,528
100%
DB
1200
48
1.73 2.26
1232
2,716
100%
DB
1350
54
2.00 2.62
1342
2,957
100%
DB
1500
60
2.27 2.98
1451
3,197
100%
DB
1650
66
2.55 3.33
1536
3,386
100%
X
X
HeavyDuty(HD)
DB
750
30
0.73 0.95
1031
2,273
100%
DB
900
36
0.95 1.24
1178
2,595
100%
DB
1050
42
1.17 1.54
1267
2,793
100%
DB
1200
48
1.40 1.84
1398
3,080
100%
DB
1350
54
1.64 2.14
1459
3,215
100%
DB
1500
60
1.88 2.46
1566
3,452
100%
DB
1650
66
2.12 2.77
1697
3,740
100%
X
X
DB
1800
72
2.36 3.08
1851
4,080
100%
X
X
TB
1800
71
2.69 3.52
2423
5,340
100%
SevereDuty(SD)
DB
750
30
0.73 0.95
1096
2,415
90%
DB
900
36
0.95 1.24
1252
2,760
90%
DB
1050
42
1.17 1.54
1353
2,981
90%
DB
1200
48
1.40 1.84
1493
3,292
90%
DB
1350
54
1.64 2.14
1599
3,524
90%
Maximumloadwithcoupler(payload+bucket)
kg
5232
4432
3802
4757
4027
lb
11,531
9,768
8,379
10,484
8,875
MaximumMaterialDensity:
2100kg/m
3
(3,500lb/yd
3
)
1800kg/m
3
(3,000lb/yd
3
)
TheaboveloadsareincompliancewithhydraulicexcavatorstandardEN474,theydonot
1500kg/m
3
(2,500lb/yd
3
)
exceed87%ofhydraulicliftingcapacityor75%oftippingcapacitywithfrontlinkagefully
extendedatgroundlinewithbucketcurled.
1200kg/m
3
(2,000lb/yd
3
)
CapacitybasedonISO7451.
900kg/m
3
(1,500lb/yd
3
)
BucketweightwithGeneralDutytips.
X
NotRecommended
Caterpillarrecommendsusingappropriateworktoolstomaximizethevaluecustomersreceivefromourproducts.Useofworktools,includingbuckets,whichare
outsideofCaterpillar’srecommendationsorspecificationsforweight,dimensions,flows,pressures,etc.mayresultinless-than-optimalperformance,including
butnotlimitedtoreductionsinproduction,stability,reliability,andcomponentdurability.Improperuseofaworktoolresultinginsweeping,prying,twistingand/or
catchingofheavyloadswillreducethelifeoftheboomandstick.
