336ELHeavyDutyReachBoomLiftCapacities–Americas
LoadPointHeight LoadatMaximumReach LoadRadiusOverFront LoadRadiusOverSide
Boom–6.50m(21'4") Counterweight–6.0mt(6.6t) Bucket–None
Stick–R3.9DB(12'10") Shoes–800mm(32")triplegrouser
1.5m/5.0ft 3.0m/10.0ft 4.5m/15.0ft 6.0m/20.0ft 7.5m/25.0ft 9.0m/30.0ft
m
ft
9.0m kg *6250 *6250 7.35
30.0ft lb *13,950 *13,950 23.64
7.5m kg *7700 7650 *5800 *5800 8.53
25.0ft lb *17,050 16,450 *12,850 *12,850 27.74
6.0m kg *8000 7550 *7500 5550 *5650 5150 9.33
20.0ft lb *17,550 16,200 *14,550 11,850 *12,450 11,500 30.48
4.5m kg *9800 *9800 *8750 7300 *8200 5450 *5650 4650 9.84
15.0ft lb *21,200 *21,200 *19,100 15,650 *17,950 11,650 *12,450 10,250 32.22
3.0m kg *15300 14850 *11600 9700 *9750 6950 8250 5250 *5850 4350 10.10
10.0ft lb *32,900 32,000 *25,100 20,850 *21,150 14,950 17,700 11,300 *12,850 9,600 33.11
1.5m kg *18450 13700 *13300 9100 10600 6650 8050 5100 *6200 4250 10.12
5.0ft lb *39,800 29,450 *28,800 19,600 22,750 14,250 17,300 10,900 *13,600 9,350 33.22
Ground
Line
kg *8550 *8550 *20100 13050 14450 8700 10300 6400 7900 4950 *6750 4300 9.93
lb *19,400 *19,400 *43,450 28,050 31,000 18,700 22,150 13,700 16,950 10,600 *14,850 9,450 32.56
–1.5m kg *8900 *8900 *13300 *13300 *20350 12800 14150 8450 10100 6200 7800 4850 7250 4550 9.48
–5.0ft lb *19,900 *19,900 *30,050 *30,050 *44,100 27,500 30,450 18,200 21,750 13,400 16,800 10,450 16,000 10,000 31.09
–3.0m kg *14100 *14100 *19400 *19400 *19500 12800 14100 8400 10100 6200 8150 5050 8.76
–10.0ft lb *31,550 *31,550 *43,850 *43,850 *42,150 27,550 30,350 18,100 21,700 13,350 18,000 11,200 28.66
–4.5m kg *20200 *20200 *24050 *24050 *17350 13000 *13200 8550 *9900 6350 *9450 6150 7.69
–15.0ft lb *45,400 *45,400 *51,900 *51,900 *37,450 28,000 *28,300 18,400 *20,850 13,700 *20,850 13,700 25.01
–6.0m kg *13250 *13250 *9400 8950 *9250 8850 6.06
–20.0ft lb *27,950 *27,950 *20,250 20,100 19.44
Boom–6.50m(21'4") Counterweight–6.0mt(6.6t) Bucket–None
Stick–R3.2DB(10'6") Shoes–800mm(32")triplegrouser
1.5m/5.0ft 3.0m/10.0ft 4.5m/15.0ft 6.0m/20.0ft 7.5m/25.0ft 9.0m/30.0ft
m
ft
7.5m kg *8800 7500 *9100 8700 6.58
25.0ft lb *20,150 19,700 21.25
6.0m kg *8900 7400 *8700 6800 7.59
20.0ft lb *19,500 15,950 *19,150 15,100 24.74
4.5m kg *13500 *13500 *10900 10100 *9550 7200 8350 5350 *8650 5850 8.21
15.0ft lb *23,600 21,750 *20,800 15,450 *19,100 12,950 26.85
3.0m kg *17150 14400 *12600 9500 *10450 6900 8200 5250 8500 5400 8.51
10.0ft lb *36,800 31,050 *27,250 20,500 *22,700 14,850 17,650 11,250 18,800 11,850 27.92
1.5m kg *19700 13450 *14100 9000 10550 6600 8050 5100 8350 5250 8.55
5.0ft lb *42,550 28,950 *30,500 19,450 22,700 14,250 17,300 10,950 18,350 11,500 28.05
Ground
Line
kg *20550 13050 14450 8700 10300 6400 7950 5000 8600 5350 8.31
lb *44,550 28,050 31,000 18,700 22,200 13,800 17,100 10,750 18,950 11,800 27.27
–1.5m kg *14500 *14500 *20150 12950 14250 8550 10200 6300 9450 5850 7.78
–5.0ft lb *32,800 *32,800 *43,750 27,850 30,650 18,400 22,000 13,600 20,850 12,950 25.48
–3.0m kg *22850 *22850 *18700 13050 *14250 8600 10250 6350 *10800 7050 6.88
–10.0ft lb *51,700 *51,700 *40,550 28,100 30,750 18,500 22,100 13,750 *23,750 15,600 22.45
–4.5m kg *21050 *21050 *15900 13350 *12050 8800 *10050 *10050 5.43
–15.0ft lb *45,350 *45,350 *34,100 28,800 *25,650 19,000 *21,950 *21,950 17.51
–6.0m kg
–20.0ft lb
*Indicatesthattheloadislimitedbyhydraulicliftingcapacityratherthantippingload.Theaboveloadsareincompliancewithhydraulicexcavatorliftcapacity
standardISO10567:2007.Theydonotexceed87%ofhydraulicliftingcapacityor75%oftippingload.Weightofallliftingaccessoriesmustbedeductedfromthe
aboveliftingcapacities.Liftingcapacitiesarebasedonthemachinestandingonafirm,uniformsupportingsurface.
AlwaysrefertotheappropriateOperationandMaintenanceManualforspecificproductinformation.
