Milton CAT 320E LRR - Manual (Page 22)

320E LRR Hydraulic Excavator Specifications
HD Boom Lift Capacities
Load Point Height Load at Maximum Reach Load Radius Over Front Load Radius Over Side
Boom – 5.7 m (18'8") Counterweight – 6.2 mt (6.8 t) Bucket – None
Stick – 2.9B1 (9'6") Shoes – 790 mm (31") triple grouser Heavy Lift Mode On
6.0 m/20.0 ft
7.5 m kg
25.0 ft lb
6.0 m kg
20.0 ft lb
4.5 m kg
15.0 ft lb
3.0 m kg
10.0 ft lb
1.5 m kg
5.0 ft lb
Ground
Line
kg
lb
–1.5 m kg
–5.0 ft lb
–3.0 m kg
–10.0 ft lb
–4.5 m kg
–15.0 ft lb
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 7.5 m/25.0 ft
m
ft
*4950 *4950 *4300 *4300 6.15
*9,500 *9,500 19.78
*5450 *5450 *3950 *3950 7.28
*12,000 *12,000 *8,750 *8,750 23.71
*6000 5650 *5650 4000 *3900 3650 7.98
*13,050 12,150 *12,400 8,600 *8,550 8,050 26.10
*8750 8200 *6900 5400 *6050 3950 *4000 3350 8.35
*18,850 17,700 *14,950 11,650 *13,150 8,450 *8,750 7,350 27.38
*10 600 7750 *7850 5200 6000 3800 *4200 3200 8.44
*22,900 16,650 *16,950 11,200 12,900 8,200 *9,250 7,100 27.70
*6600 *6600 *11 650 7450 8150 5050 5900 3750 *4650 3300 8.26
*15,150 *15,150 *25,200 16,050 17,550 10,800 12,700 8,000 *10,250 7,200 27.09
*7050 *7050 *11 400 *11 400 *11 750 7400 8100 4950 5900 3700 *5500 3550 7.78
*15,750 *15,750 *25,850 *25,850 *25,450 15,850 17,400 10,650 12,650 7,950 *12,100 7,800 25.48
*12 100 *12 100 *15 600 14 300 *11 000 7450 8100 5000 6600 4150 6.94
*27,100 *27,100 *33,750 30,650 *23,800 16,000 17,450 10,750 14,650 9,150 22.67
*12 450 *12 450 *8950 7650 *6800 5650 5.60
*26,650 *26,650 *19,100 16,450 *14,900 12,750 18.08
Boom – 5.7 m (18'8") Counterweight – 6.9 mt (7.6 t) Bucket – None
Stick – 2.9B1 (9'6") Shoes – 790 mm (31") triple grouser Heavy Lift Mode On
6.0 m/20.0 ft
7.5 m kg
25.0 ft lb
6.0 m kg
20.0 ft lb
4.5 m kg
15.0 ft lb
3.0 m kg
10.0 ft lb
1.5 m kg
5.0 ft lb
Ground
Line
kg
lb
–1.5 m kg
–5.0 ft lb
–3.0 m kg
–10.0 ft lb
–4.5 m kg
–15.0 ft lb
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 7.5 m/25.0 ft
m
ft
*4950 *4950 *4300 *4300 6.15
*9,500 *9,500 19.78
*5450 *5450 *3950 *3950 7.28
*12,000 *12,000 *8,750 *8,750 23.71
*6000 6000 *5650 4300 *3900 3850 7.98
*13,050 12,900 *12,400 9,200 *8,550 8,550 26.10
*8750 8700 *6900 5750 *6050 4200 *4000 3550 8.35
*18,850 18,800 *14,950 12,400 *13,150 9,000 *8,750 7,850 27.38
*10 600 8250 *7850 5550 6350 4050 *4200 3450 8.44
*22,900 17,700 *16,950 11,900 13,650 8,750 *9,250 7,550 27.70
*6600 *6600 *11 650 7950 *8500 5350 6250 4000 *4650 3500 8.26
*15,150 *15,150 *25,200 17,100 *18,400 11,550 13,450 8,550 *10,250 7,700 27.09
*7050 *7050 *11 400 *11 400 *11 750 7850 8550 5300 6200 3950 *5500 3800 7.78
*15,750 *15,750 *25,850 *25,850 *25,450 16,950 18,350 11,400 13,400 8,500 *12,100 8,300 25.48
*12 100 *12 100 *15 600 15 200 *11 000 7900 *8200 5300 *6700 4400 6.94
*27,100 *27,100 *33,750 32,600 *23,800 17,050 *17,600 11,450 *14,750 9,750 22.67
*12 450 *12 450 *8950 8100 *6800 6000 5.60
*26,650 *26,650 *19,050 17,500 *14,900 13,550 18.08
*Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity
standard ISO 10567:2007. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted from the
above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface. The use of a work tool attachment point to
handle/lift objects, could affect the machine lift performance.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
22
