106 PED-ST
Vishay BCcomponents Aluminum Capacitors
Power Eurodin Screw Terminals
www.vishay.com For technical questions, contact: [email protected] Document Number: 28384
180 Revision: 27-May-09
Note
• Unless otherwise specified, all electrical values in tables 2 and 3
apply at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 106 PED-ST series
10 000 µF/25 V; - 10 %/+ 30 %
Nominal case size:
Ø 35 mm x 80 mm; ST version
Table 2
76 x 114 HC 2B 115.8 120.2 76.4 31.8 5.5 3.5 18.3 13.0 M6 8.5 M12 16.0 800 12
76 x 146 2A 145.8 151.7 76.4 31.8 7.0 4.6 11.7 7.9 M5 9.5 M12 16.0 1000 12
76 x 146 HC 2B 145.8 150.2 76.4 31.8 5.5 3.5 18.3 13.0 M6 8.5 M12 16.0 1000 12
76 x 220 2A 219.8 225.7 76.4 31.8 7.0 4.6 11.7 7.9 M5 9.5 M12 16.0 1500 10
76 x 220 HC 2B 219.8 224.2 76.4 31.8 5.5 3.5 18.3 13.0 M6 8.5 M12 16.0 1500 10
90 x 146 HC 2B 150.1 155.4 89.4 31.8 7.9 0.0 13.0 13.0 M6 10.0 M12 16.0 1300 10
90 x 220 HC 2B 218.1 223.4 89.4 31.8 7.9 0.0 13.0 13.0 M6 10.0 M12 16.0 2000 10
Note
• For bolt version holds:
1. L = L standard - 0.5 mm
2. L
t
= L
t
standard - 0.5 mm
DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES
DESIGN DRAWING L ± 1 L t
± 1 D ± 1 P ± 0.3 T ± 0.2 H ± 0.3 B ± 0.3 d
1
± 0.1 M S - 0 Mb l
b
± 0.1
MASS
(g)
PACKAGING
QUANTITIES
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
Rated capacitance at 100 Hz, tolerance - 10 % to + 30 %
I
R
Rated RMS ripple current at 100 Hz, 85 °C
I
L5
Max. leakage current after 5 minutes at U
R
ESR Max. equivalent series resistance at 100 Hz
Z Impedance at 20 kHz
Ordering code: MAL2 106 16103 E3
Former 12NC: 2222 106 16103
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE
SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
L5
5 min
(mA)
ESR
max.
100 Hz
(m Ω)
Z
max.
20 kHz
(m Ω)
STANDARD HIGH POST M5 DISC HIGH CURRENT M6 DISC
ST
ORDERING
CODE
MAL2106.......
ST BOLT NUT
ORDERING
CODE
MAL2106.......
ST
ORDERING
CODE
MAL2106.......
ST BOLT NUT
ORDERING
CODE
MAL2106.......
25
4700 35 x 60 6.0 0.24 53 32 16472E3 56472E3 - -
6800 35 x 60 6.5 0.34 43 29 16682E3 56682E3 - -
10 000 35 x 80 7.9 0.50 32 22 16103E3 56103E3 - -
15 000 35 x 105 9.3 0.75 25 18 16153E3 56153E3 - -
22 000 50 x 80 14.0 1.10 15 11 16223E3 56223E3 - -
33 000 50 x 105 16.4 1.65 12 9 16333E3 56333E3 - -
47 000 65 x 105 23.2 3.35 8 6 16473E3 56473E3 36473E3 76473E3
68 000 65 x 105 23.5 3.40 8 6 16683E3 56683E3 36683E3 76683E3
100 000 76 x 105 30.1 5.00 6 5 16104E3 56104E3 36104E3 76104E3
150 000 76 x 146 34.5 7.5 5 5 16154E3 56154E3 36154E3 76154E3
220 000 76 x 220 40.8 11.0 5 5 16224E3 56224E3 36224E3 76224E3
220 000 90 x 146 50 11.0 5 5 - - 46224E3 86224E3
330 000 90 x 220 50 16.5 5 5 - - 46334E3 86334E3
40
3300 35 x 60 5.7 0.27 56 32 17332E3 57332E3 - -
4700 35 x 60 6.0 0.38 48 31 17472E3 57472E3 - -
6800 35 x 80 7.3 0.55 36 24 17682E3 57682E3 - -
10 000 35 x 105 10.9 0.80 19 11 17103E3 57103E3 - -
15 000 50 x 80 13.0 1.20 17 12 17153E3 57153E3 - -
22 000 50 x 105 15.2 1.76 13 10 17223E3 57223E3 - -
