3

54-94-104MT..KPbF Series

Three Phase AC Switch

(Power Modules), 50 A to 100 A

Vishay High Power Products

Note

(1)

Available with dV/dt = 1000 V/µs, to complete code add S90 i. e. 104MT160KBS90

BLOCKING

PARAMETER

SYMBOL

TEST CONDITIONS

54MT.K

94MT.K

104MT.K

UNITS

RMS isolation voltage

V

INS

T

J

= 25 °C all terminal shorted

f = 50 Hz, t = 1 s

4000

V

Maximum critical rate of rise of
off-state voltage

dV/dt

(1)

T

J

= T

J

maximum, linear to 0.67 V

DRM

,

gate open circuit

500

V/µs

TRIGGERING

PARAMETER

SYMBOL

TEST CONDITIONS

54MT.K

94MT.K

104MT.K

UNITS

Maximum peak gate power

P

GM

T

J

= T

J

maximum

10

W

Maximum average gate power

P

G(AV)

2.5

Maximum peak gate current

I

GM

2.5

A

Maximum peak negative
gate voltage

- V

GT

10

V

Maximum required DC gate
voltage to trigger

V

GT

T

J

= - 40 °C

Anode supply = 6 V, resistive
load

4.0

T

J

= 25 °C

2.5

T

J

= 125 °C

1.7

Maximum required DC gate
current to trigger

I

GT

T

J

= - 40 °C

270

mA

T

J

= 25 °C

150

T

J

= 125 °C

80

Maximum gate voltage
that will not trigger

V

GD

T

J

= T

J

maximum, rated V

DRM

applied

0.25

V

Maximum gate current
that will not trigger

I

GD

6

mA

THERMAL AND MECHANICAL SPECIFICATIONS

PARAMETER

SYMBOL

TEST CONDITIONS

54MT.K

94MT.K

104MT.K

UNITS

Maximum junction operating
and storage temperature range

T

J

, T

Stg

- 40 to 125

°C

Maximum thermal resistance,
junction to case

R

thJC

DC operation per single AC switch

0.52

0.39

0.34

K/W

DC operation per junction

1.05

0.77

0.69

180 °C sine cond. angle per single AC switch

0.56

0.40

0.36

180 °C sine cond. angle per junction

1.12

0.80

0.72

Maximum thermal resistance,
case to heatsink

R

thCS

Per module
Mounting surface smooth, flat and grased

0.03

Mounting
torque ± 100 %

to heatsink

A mounting compound is recommended and
the torque should be rechecked after a period
of 3 hours to allow for the spread of the
compound. Lubricated threads.

4 to 6

Nm

to terminal

3 to 4

Approximate weight

225

g
