Standard Recovery Diodes
(Stud Version), 320 A
240U(R).. Series
Vishay High Power Products
FEATURES
• Diffused diode
• Wide current range
• High voltage ratings up to 1200 V
• High surge current capabilities
• Stud cathode and stud anode version
• Hermetic metal case
• RoHS compliant
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Welders
• Power supplies
• Machine tool controls
• High power drives
• Medium traction applications
• Battery charges
• Freewheeling diodes
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
320 A
DO-205AB (DO-9)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
F(AV)
320 A
T
C
100 °C
I
F(RMS)
500 A
I
FSM
50 Hz 4500
A
60 Hz 4700
I 2 t
50 Hz 101
kA 2 s
60 Hz 92
V
RRM
Range 600 to 1200 V
T
J
- 40 to 180 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
240U(R)..
60 600 700
15
80 800 900
100 1000 1100
120 1200 1300
