10ETS..FP
SAFE IR Series
Preliminary Data Sheet I2142 rev. A 03/99
I
F(AV)
Max. Average Forward Current 10 A @ T
C
= 105° C, 180° conduction half sine wave
I
FSM
Max. Peak One Cycle Non-Repetitive 170 10ms Sine pulse, rated V
RRM
applied
Surge Current 200 10ms Sine pulse, no voltage reapplied
I 2 t Max. I 2 t for fusing 130 10ms Sine pulse, rated V
RRM
applied
145 10ms Sine pulse, no voltage reapplied
I
2 √
t Max. I
2 √
t for fusing 1450 A
2 √
s t = 0.1 to 10ms, no voltage reapplied
Part Number
V
RRM
, maximum V
RSM
, maximum non repetitive I
R R M
peak reverse voltage peak reverse voltage 150°C
V V mA
10ETS08FP 800 900 0.5
10ETS12FP 1200 1300
10ETS16FP 1600 1700
Voltage Ratings
T
J
Max. Junction Temperature Range - 40 to 150 °C
T
s t g
Max. Storage Temperature Range - 40 to 150 °C
R
thJC
Max. Thermal Resistance Junction 2.5 °C/W DC operation
to Case
R
thJA
Max. Thermal Resistance Junction 62 °C/W
to Ambient
R
thCS
Typical Thermal Resistance, Case to 0.5 °C/W Mounting surface , smooth and greased
Heatsink
wt Approximate Weight 2 (0.07) g (oz.)
T Mounting Torque Min. 6 (5)
Max. 12 (10)
Case Style TO-220 FULLPAK (94/V0)
Thermal-Mechanical Specifications
Parameters 10ETS..FP Units Conditions
Kg-cm
(Ibf-in)
Absolute Maximum Ratings
Electrical Specifications
Parameters 10ETS..FP Units Conditions
A A
2 s
V
FM
Max. Forward Voltage Drop 1.1 V @ 10A, T
J
= 25°C
r
t
Forward slope resistance 20 m Ω
V
F(TO)
Threshold voltage 0.82 V
I
RM
Max. Reverse Leakage Current 0.05 T
J
= 25 °C
0.50 T
J
= 150 °C
Parameters 10ETS..FP Units Conditions
T
J
= 150°C
V
R
= rated V
RRM
mA
Provide terminal coating for voltages above 1200V
