162/163 PLL-PW
Vishay BCcomponents Aluminum Capacitors
Power Long Life Printed Wiring
www.vishay.com For technical questions, contact: [email protected] Document Number: 28347
160 Revision: 07-Oct-09
Note
• Unless otherwise specified, all electrical values in tables 2 and 3
apply at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 162 series
10 000 µF/25 V; ± 20 %
Nominal case size: Ø 30 mm x 40 mm
Table 2
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz
I
R
rated RMS ripple current at 100 Hz and 105
°C
I
L1
max. leakage current after 1 minute at U
R
I
L5
max. leakage current after 5 minutes at U
R
ESR max. equivalent series resistance at 100 Hz
Z max. impedance at 10 kHz
Ordering code: MAL2 162 56103 E3
Former 12NC: 2222 162 56103
ELECTRICAL DATA AND ORDERING INFORMATION FOR 162 SERIES
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L (mm)
I
R
100 Hz
105 °C
(A)
I
L1
1 min
(mA)
I
L5
5 min
(mA)
ESR
100 Hz
(m Ω)
Z
10 kHz
(m Ω)
ORDERING CODE
MAL2162.......
10
10 000 25 x 30 3.17 0.60 0.20 48 37 54103E3
15 000 25 x 40 4.21 0.90 0.30 34 27 54153E3
22 000 30 x 40 5.05 1.32 0.44 29 23 54223E3
33 000 35 x 40 5.63 1.98 0.66 27 22 54333E3
47 000 35 x 50 6.19 2.82 0.94 26 21 54473E3
47 000 40 x 40 6.19 2.82 0.94 26 21 44473E3
68 000 40 x 50 7.64 4.08 1.36 21 18 54683E3
100 000 40 x 70 10.0 6.00 2.00 16 15 54104E3
150 000 40 x 100 12.9 9.00 3.00 13 12 54154E3
16
6800 25 x 30 3.11 0.65 0.22 50 37 55682E3
10 000 25 x 40 4.09 0.96 0.32 36 27 55103E3
15 000 30 x 40 4.97 1.44 0.48 30 23 55153E3
22 000 35 x 40 5.53 2.12 0.71 29 22 55223E3
33 000 35 x 50 6.08 3.17 1.06 28 21 55333E3
33 000 40 x 40 6.08 3.17 1.06 28 21 45333E3
47 000 40 x 50 7.46 4.52 1.51 22 18 55473E3
68 000 40 x 70 9.70 6.53 2.18 17 15 55683E3
100 000 40 x 100 12.90 9.60 3.20 13 12 55104E3
25
4700 25 x 30 2.94 0.71 0.24 56 37 56472E3
6800 25 x 40 3.93 1.02 0.34 39 27 56682E3
10 000 30 x 40 4.81 1.50 0.50 32 23 56103E3
15 000 35 x 40 5.43 2.25 0.75 30 22 56153E3
22 000 35 x 50 5.98 3.30 1.10 29 21 56223E3
22 000 40 x 40 5.98 3.30 1.10 29 21 46223E3
33 000 40 x 50 7.30 4.95 1.65 23 18 56333E3
47 000 40 x 70 9.43 7.05 2.35 18 15 56473E3
68 000 40 x 100 12.44 10.20 3.40 14 12 56683E3
40
2200 25 x 30 2.36 0.53 0.18 87 54 57222E3
3300 25 x 40 3.17 0.79 0.27 60 38 57332E3
4700 30 x 40 3.93 1.13 0.38 48 33 57472E3
6800 35 x 40 4.59 1.63 0.55 42 31 57682E3
10 000 35 x 50 5.03 2.40 0.80 41 29 57103E3
10 000 40 x 40 5.03 2.40 0.80 41 29 47103E3
15 000 40 x 50 6.09 3.60 1.20 33 24 57153E3
22 000 40 x 70 8.34 5.28 1.76 23 18 57223E3
33 000 40 x 100 10.97 7.92 2.64 18 15 57333E3
63
1000 25 x 30 1.55 0.38 0.13 202 155 58102E3
1500 25 x 40 2.10 0.57 0.19 137 109 58152E3
2200 30 x 40 2.72 0.83 0.28 100 79 58222E3
3300 35 x 40 3.44 1.25 0.42 75 61 58332E3
4700 35 x 50 4.09 1.78 0.60 62 53 58472E3
4700 40 x 40 4.09 1.78 0.60 62 53 48472E3
6800 40 x 50 5.10 2.57 0.86 47 40 58682E3
10 000 40 x 70 6.86 3.78 1.26 34 29 58103E3
15 000 40 x 100 9.31 5.67 1.89 25 21 58153E3
100
470 25 x 30 1.42 0.28 0.10 240 155 59471E3
680 25 x 40 1.90 0.41 0.14 167 109 59681E3
1000 30 x 40 2.48 0.60 0.20 120 79 59102E3
1500 35 x 40 3.17 0.90 0.30 88 61 59152E3
2200 35 x 50 3.79 1.32 0.44 72 53 59222E3
2200 40 x 40 3.79 1.32 0.44 72 53 49222E3
3300 40 x 50 4.81 1.98 0.66 53 40 59332E3
4700 40 x 70 6.49 2.82 0.94 38 29 59472E3
6800 40 x 100 8.80 4.08 1.36 28 21 59682E3
