www.vishay.com For technical questions, contact: [email protected] Document Number: 94500
4 Revision: 30-Aug-07
60CPH03PbF
Vishay High Power Products Hyperfast Rectifier, 60 A
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current
Fig. 7 - Typical Reverse Recovery Time vs. dI
F
/dt
Fig. 6 - Forward Power Loss Characteristics
Fig. 8 - Typical Stored Charge vs. dI
F
/dt
Note
(1) Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= Rated V
R
120
160
140
180
Allowable
C
ase Temperature (°
C
)
I
F(AV)
- Average Forward Current (A)
25 5 10 15 20 30 40 35 45 0
DC
See note (1)
Square wave (D = 0.50)
Rated V
R
applied
10
20
30
40
50
60
70
80
t rr
(ns)
dI
F
/dt (Aµs)
1000 100
I
F
= 30 A, 125 °C
I
F
= 30 A, 25 °C
0
5
10
15
20
25
30
35
40
45
50
Average Power Loss (W)
I
F(AV)
- Average Forward Current (A)
10 5 15 25 20 30 35 45 40 50 0
RMS limit
D = 0.01
D = 0.02
D = 0.05
D = 0.10
D = 0.20
D = 0.50
DC
100
10
1000
Q
rr
(nC)
dI
F
/dt (A/µs)
1000 100
I
F
= 30 A, 125 °C
I
F
= 30 A, 25 °C
