C&H Technology 60CPH03PbF - Manual (Page 2)

Document Number: 94500 For technical questions, contact: [email protected] www.vishay.com
Revision: 30-Aug-07 1
Hyperfast Rectifier, 60 A
60CPH03PbF
Vishay High Power Products
FEATURES
• Ultrafast recovery time
• Low forward voltage drop
• Low leakage current
• 175 °C operating junction temperature
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level
DESCRIPTIONS/APPLICATIONS
60CPH03PbF series are the state of the art ultrafast
recovery rectifiers designed with optimized performance of
forward voltage drop and ultrafast recovery time.
The planar structure and the platinum doped life time control
guarantee the best overall performance, ruggedness and
reliability characteristics.
These devices are intended for use in the output rectification
stage of SMPS, UPS, dc-to-dc converters as well as
freewheeling diodes in low voltage inverters and chopper
motor drives.
Their extremely optimized stored charge and low recovery
current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
PRODUCT SUMMARY
I
F(AV)
60 A
V
R
300 V
t
rr
55 ns
TO-247AC
Base
common
cathode
Common
cathode
2
2
1 3
Anode
1
Anode
2
RoHS
COMPLIANT
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL TEST CONDITIONS MAX. UNITS
Repetitive peak reverse voltage V
RRM
300 V
Average rectified forward current
per leg
I
F(AV)
T
C
= 143 °C
30
A total device 60
Non-repetitive peak surge current per leg I
FSM
T
J
= 25 °C 300
Operating junction and storage temperature T
J
, T
Stg
- 65 to 175 °C
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Breakdown voltage,
blocking voltage
V
BR
, V
R
I
R
= 100 µA 300 - -
V
Forward voltage V
F
I
F
= 30 A, T
J
= 25 °C - 1.08 1.25
I
F
= 30 A, T
J
= 125 °C - 0.92 1.00
Reverse leakage current I
R
V
R
= V
R
rated - 0.05 60
µA
T
J
= 125 °C, V
R
= V
R
rated - 20 300
Junction capacitance C
T
V
R
= 300 V - 70 - pF
Series inductance L
S
Measured lead to lead 5 mm from package body - 3.5 - nH
