095 PLL-4TSI
Aluminum Capacitors
Power Long Life 4 Terminal Snap-In
Vishay BCcomponents
RIPPLE CURRENT AND USEFUL LIFE
Table 3
ADDITIONAL ELECTRICAL DATA
PARAMETER
CONDITIONS
VALUE
Voltage
Surge voltage
≥ 350 V versions
U
s
= 1.1 x U
R
Reverse voltage
U
rev
≤ 1
Current
Leakage current
After 1 minute at U
R
I
L1
≤ 0.006 C
R
x U
R
+ 4 µA
After 5 minutes at U
R
I
L5
≤ 0.002 C
R
x U
R
+ 4 µA
Inductance
Equivalent series inductance (ESL)
All case sizes
ca. 20 nH
2.6
2.4
2.2
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.5
0.0
40
50
60
70
80
90
100
(1)
4.
0
6.
0
2.
0
1.
5
30
10
3.
0
2
0
1.
0
I
A
I
R
lifetime multiplier
40
CCC205-05
T
amb
(°C)
Fig.6
Multiplier of useful life as a function of ambient temperature and ripple current load
I
A
= actual ripple current at 100 Hz.
I
R
= rated ripple current at 100 Hz and 85 °C
(1)
Useful life at 85 °C and I
R
applied:
10 000 hours
MULTIPLIER OF RIPPLE CURRENT (I
R
) AS A FUNCTION OF FREQUENCY
FREQUENCY
(Hz)
I
R
MULTIPLIER
50
0.9
100
1.0
200
1.2
400
1.3
1000
1.4
10 000
1.5
