095 PLL-4TSI
Vishay BCcomponents Aluminum Capacitors
Power Long Life 4 Terminal Snap-In
www.vishay.com For technical questions, contact: [email protected] Document Number: 28393
4 Revision: 08-Aug-08
400
470 35 x 50 3.2 380 215 126 16471E3 66471E3
470 40 x 40 3.0 380 222 132 26471E3 76471E3
560 35 x 60 3.7 452 180 105 16561E3 66561E3
560 45 x 40 3.2 452 192 116 36561E3 -
680 35 x 70 4.1 548 149 87 16681E3 66681E3
680 40 x 60 4.3 548 151 89 26681E3 76681E3
680 45 x 50 4.3 548 156 93 36681E3 -
820 35 x 80 4.7 660 125 73 16821E3 66821E3
820 40 x 60 4.6 660 129 77 26821E3 76821E3
1000 35 x 100 5.9 804 102 60 16102E3 66102E3
1000 40 x 70 5.2 804 107 64 26102E3 76102E3
1000 45 x 60 5.4 804 110 67 36102E3 -
1500 40 x 100 7.2 1204 72 43 26152E3 76152E3
1500 45 x 80 6.7 1204 75 47 36152E3 -
1800 45 x 100 7.9 1444 63 38 36182E3 -
420
470 35 x 50 3.1 399 232 141 14471E3 64471E3
470 40 x 40 3.0 399 238 147 24471E3 74471E3
560 35 x 60 3.6 474 194 119 14561E3 64561E3
680 35 x 70 4.1 575 161 98 14681E3 64681E3
680 40 x 60 4.3 575 163 100 24681E3 74681E3
680 45 x 50 4.3 575 167 104 34681E3 -
820 35 x 80 4.6 693 134 82 14821E3 64821E3
820 40 x 70 4.8 693 136 84 24821E3 74821E3
820 45 x 50 4.6 693 143 91 34821E3 -
1000 35 x 100 5.8 844 110 67 14102E3 64102E3
1000 40 x 80 5.4 844 112 69 24102E3 74102E3
1000 45 x 60 5.4 844 117 75 34102E3 -
1500 40 x 100 7.2 1264 77 48 24152E3 74152E3
1500 45 x 80 6.7 1264 80 51 34152E3 -
1800 45 x 100 7.8 1516 67 43 34182E3 -
450
390 35 x 50 2.9 355 246 142 17391E3 67391E3
390 40 x 40 2.8 355 253 148 27391E3 77391E3
470 35 x 60 3.4 427 204 118 17471E3 67471E3
470 40 x 50 3.5 427 208 121 27471E3 77471E3
470 45 x 40 3.0 427 217 129 37471E3 -
560 35 x 70 3.8 508 172 99 17561E3 67561E3
560 40 x 60 4.0 508 174 101 27561E3 77561E3
680 35 x 80 4.3 616 143 82 17681E3 67681E3
680 40 x 60 4.3 616 147 87 27681E3 77681E3
680 45 x 50 4.3 616 153 91 37681E3 -
820 40 x 70 4.8 742 123 72 27821E3 77821E3
820 45 x 60 5.0 742 126 76 37821E3 -
1000 40 x 100 6.0 904 99 57 27102E3 77102E3
1000 45 x 70 5.6 904 104 63 37102E3 -
1200 40 x 100 6.4 1084 85 50 27122E3 77122E3
1500 45 x 100 7.4 1354 71 42 37152E3 -
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
L(5)
5 min
(µA)
ESR max.
100 Hz
(m Ω)
Z max.
10 kHz
(m Ω)
ORDERING CODE
MAL2095.......
4T-SI PW
