286
CM200DY-28H
Dual IGBTMOD™ H-Series Module
200 Amperes/1400 Volts
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings, T
j
= 25
°
C unless otherwise specified
Ratings Symbol CM200DY-28H Units
Junction Temperature T
j
–40 to 150 ° C
Storage Temperature T
stg
–40 to 125
°
C
Collector-Emitter Voltage (G-E SHORT) V
CES
1400 Volts
Gate-Emitter Voltage V
GES
±
20 Volts
Collector Current I C 200 Amperes
Peak Collector Current I
CM
400* Amperes
Diode Forward Current I
F
200 Amperes
Diode Forward Surge Current I
FM
400* Amperes
Power Dissipation P
d
1500 Watts
Max. Mounting Torque M6 Terminal Screws – 26 in-lb
Max. Mounting Torque M6 Mounting Screws – 26 in-lb
Module Weight (Typical) – 400 Grams
V Isolation V
RMS
2500 Volts
* Pulse width and repetition rate should be such that device junction temperature does not exceed the device rating.
Static Electrical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Collector-Cutoff Current I
CES
V
CE
= V
CES
, V
GE
= 0V – – 1.0 mA
Gate Leakage Current I
GES
V
GE
= V
GES
, V
CE
= 0V – – 0.5
µ
A
Gate-Emitter Threshold Voltage V
GE(th)
I
C
= 20mA, V
CE
= 10V 5.0 6.5 8.0 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
I
C
= 200A, V
GE
= 15V – 3.1 4.2** Volts
I
C
= 200A, V
GE
= 15V, T
j
= 150 ° C – 2.95 – Volts
Total Gate Charge Q
G
V
CC
= 800V, I
C
= 200A, V
GE
= 15V – 1020 – nC
Diode Forward Voltage V
FM
I
E
= 200A, V
GE
= 0V – – 3.8 Volts
** Pulse width and repetition rate should be such that device junction temperature rise is negligible.
Dynamic Electrical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Input Capacitance C
ies
– – 40 nF
Output Capacitance C oes V GE = 0V, V C E = 10V, f = 1MHz – – 14 nF
Reverse Transfer Capacitance C
res
– – 8 nF
Resistive Turn-on Delay Time t
d(on)
– – 250 ns
Load Rise Time t
r
V
CC
= 800V, I
C
= 200A, – – 400 ns
Switching Turn-off Delay Time t
d(off)
V
GE1
= V
GE2
= 15V, R
G
= 1.6
Ω
– – 300 ns
Times Fall Time t
f
– – 500 ns
Diode Reverse Recovery Time t rr I E = 200A, di E /dt = –400A/
µ
s – – 300 ns
Diode Reverse Recovery Charge Q
rr
I
E
= 200A, di
E
/dt = –400A/
µ
s – 2.0 –
µ
C
Thermal and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Thermal Resistance, Junction to Case R
th(j-c)
Per IGBT – – 0.085 ° C/W
Thermal Resistance, Junction to Case R
th(j-c)
Per FWDi – – 0.18 ° C/W
Contact Thermal Resistance R
th(c-f)
Per Module, Thermal Grease Applied – – 0.045
°
C/W
