096 PLL-4TSI
Vishay BCcomponents Aluminum Capacitors
Power Long Life 4-Terminal Snap-In
www.vishay.com For technical questions, contact: [email protected] Document Number: 28392
4 Revision: 08-Aug-08
385
680 35 x 50 3.7 528 140 88 18681E3 68681E3
680 40 x 50 4.2 528 140 87 28681E3 78681E3
820 35 x 60 4.4 635 116 73 18821E3 68821E3
820 40 x 50 4.5 635 120 76 28821E3 78821E3
1000 35 x 70 5.0 774 96 60 18102E3 68102E3
1000 40 x 60 5.1 774 99 63 28102E3 78102E3
1200 35 x 80 5.5 928 81 51 18122E3 68122E3
1200 40 x 70 5.7 928 83 53 28122E3 78122E3
1500 40 x 80 6.5 1159 68 43 28152E3 78152E3
1500 45 x 60 6.2 1159 74 50 38152E3 -
1800 40 x 100 7.7 1390 56 36 28182E3 78182E3
1800 45 x 70 7.0 1390 62 43 38182E3 -
2200 40 x 100 8.2 1698 49 32 28222E3 78222E3
2700 45 x 100 9.1 2083 43 29 38272E3 -
400
680 35 x 60 4.1 548 134 82 16681E3 66681E3
680 40 x 50 4.2 548 138 85 26681E3 76681E3
820 35 x 60 4.4 660 114 71 16821E3 66821E3
820 40 x 50 4.5 660 119 75 26821E3 76821E3
1000 35 x 70 5.0 804 94 59 16102E3 66102E3
1000 40 x 60 5.1 804 97 62 26102E3 76102E3
1000 45 x 50 5.1 804 103 67 36102E3 -
1200 35 x 80 5.5 964 80 50 16122E3 66122E3
1200 40 x 70 5.7 964 82 52 26122E3 76122E3
1200 45 x 60 5.9 964 85 55 36122E3 -
1500 35 x 100 7.1 1204 64 40 16152E3 66152E3
1500 40 x 80 6.5 1204 67 43 26152E3 76152E3
1500 45 x 70 6.6 1204 69 46 36152E3 -
1800 40 x 100 7.7 1444 56 35 26182E3 76182E3
1800 45 x 80 7.3 1444 59 39 36182E3 -
2200 45 x 100 8.6 1764 48 32 36222E3 -
2700 45 x 100 9.1 2164 42 29 36272E3 -
420
680 35 x 60 4.1 575 137 85 14681E3 64681E3
680 40 x 50 4.2 575 141 89 24681E3 74681E3
820 35 x 70 4.6 693 114 71 14821E3 64821E3
820 40 x 60 4.7 693 117 74 24821E3 74821E3
1000 35 x 80 5.1 844 95 59 14102E3 64102E3
1000 40 x 60 5.1 844 100 64 24102E3 74102E3
1200 40 x 70 5.7 1012 84 54 24122E3 74122E3
1500 40 x 100 7.2 1264 66 42 24152E3 74152E3
1500 45 x 70 6.6 1264 71 48 34152E3 -
1800 40 x 100 7.6 1516 57 37 24182E3 74182E3
1800 45 x 80 7.2 1516 60 40 34182E3 -
2200 45 x 100 8.5 1852 49 33 34222E3 -
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
L(5)
5 min
(µA)
ESR
100 Hz
(m Ω)
Z max.
10 kHz
(m Ω)
CATALOG NUMBER
MAL2096.......
4T-SI PW
