090 PUL-SI
Aluminum Capacitors
Power Ultra Long Life Snap-In
Vishay BCcomponents
Table 1
Notes
(1) ESR at 120 Hz is approximately 0.95 x ESR 100 Hz
• Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20 °C, P = 86 to 106 kPa, RH = 45 to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 090 series
3300 µF/80 V; ± 20 %
Nominal case size: Ø 30 x 40 mm
2-terminal snap-in:
3-terminal snap-in:
Table 2
DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
Ø D x L
Ø D
max.
L
max.
MASS
(g)
PACKAGING QUANTITIES
(units per box)
CARDBOARD BOX DIMENSIONS
L x W x H
(mm)
22 x 25 23 27 12 100 260 x 250 x 39
22 x 30 23 32 16 100 260 x 250 x 44
25 x 30 26 32 22 100 290 x 280 x 44
25 x 40 26 42 27 100 290 x 280 x 54
30 x 30 31 32 30 100 340 x 330 x 44
30 x 35 31 37 35 100 340 x 330 x 49
30 x 40 31 42 40 100 340 x 330 x 54
35 x 40 36 42 55 50 390 x 198 x 54
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz
I
R
rated RMS ripple current at 100 Hz or 10 kHz,
105
°C
I
L5
max. leakage current after 5 minutes at U
R
ESR max. equivalent series resistance at 100 Hz (1)
Z max. impedance at 10 kHz
Ordering code: MAL2 090 32332 E3
Former 12NC: 2222 090 32332
Ordering code: MAL2 090 72332 E3
Former 12NC: 2222 090 72332
ELECTRICAL DATA AND ORDERING INFORMATION FOR 2 AND 3 TERMINAL SNAP-IN VERSIONS
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
105 °C
(A)
I
R
10 kHz
105 °C
(A)
I
L5
5 min
(mA)
MAX. ESR
100 Hz (1)
(m
Ω)
MAX. Z
10 kHz
(m
Ω)
ORDERING CODE
MAL2090.......
2-TERM. SI 3-TERM. SI
16
6800 22 x 25 2.8 3.3 222 82 66 15682E3 55682E3
10 000 22 x 30 3.4 4.0 324 59 48 15103E3 55103E3
15 000 25 x 30 3.6 4.3 484 53 44 25153E3 65153E3
22 000 25 x 40 4.5 5.5 708 38 33 25223E3 65223E3
22 000 30 x 30 3.7 4.5 708 54 43 35223E3 75223E3
27 000 30 x 35 4.2 5.1 868 45 36 35273E3 75273E3
33 000 30 x 40 4.7 5.6 1060 39 32 35333E3 75333E3
47 000 35 x 40 4.8 5.8 1508 43 32 45473E3 85473E3
25
4700 22 x 25 2.6 3.1 236 89 66 16472E3 56472E3
6800 22 x 30 3.2 3.8 341 65 49 16682E3 56682E3
8200 25 x 30 3.4 4.1 411 60 46 26822E3 66822E3
10 000 25 x 40 4.3 5.1 501 46 35 26103E3 66103E3
12 000 25 x 40 4.3 5.2 601 43 34 26123E3 66123E3
12 000 30 x 30 3.7 4.5 601 56 44 36123E3 76123E3
15 000 30 x 35 4.2 5.1 751 46 36 16153E3 56153E3
15 000 30 x 40 4.8 5.7 751 40 33 36153E3 76153E3
22 000 35 x 40 5.1 6.1 1101 40 31 46223E3 86223E3
35
4700 22 x 30 2.8 3.4 330 78 53 10472E3 50472E3
6800 25 x 30 3.0 3.6 477 70 50 20682E3 60682E3
10 000 25 x 40 3.9 4.7 701 49 36 20103E3 60103E3
10 000 30 x 30 3.2 3.9 701 70 49 30103E3 70103E3
15 000 30 x 40 4.1 4.9 1051 49 35 30153E3 70153E3
22 000 35 x 40 4.2 5.0 1541 55 35 40223E3 80223E3
