090 PUL-SI
Vishay BCcomponents
Aluminum Capacitors
Power Ultra Long Life Snap-In
www.vishay.com
For technical questions, contact: [email protected]
Document Number: 28387
2
Revision: 18-Aug-08
DIMENSIONS in millimeters AND AVAILABLE FORMS
12 000
-
25 x 40
30 x 30
-
-
-
-
-
-
15 000
25 x 30
30 x 35
30 x 40
30 x 40
35 x 40
-
-
-
-
18 000
-
-
-
35 x 40
-
-
-
-
22 000
25 x 40
30 x 30
35 x 40
35 x 40
-
-
-
-
-
27 000
30 x 35
-
-
-
-
-
-
-
33 000
30 x 40
-
-
-
-
-
-
-
39 000
-
-
-
-
-
-
-
-
47 000
30 x 40
35 x 40
-
-
-
-
-
-
-
SELECTION CHART FOR C
R
, U
R
AND RELEVANT NOMINAL CASE SIZES (Ø D x L in mm)
C
R
(µF)
U
R
(V)
16
25
35
40
50
63
80
100
TWO TERMINAL SNAP-IN
THREE TERMINAL SNAP-IN
L
Bottom view
5.8 mm
+ 0
- 1
Ø D
L + 2 max.
+ TERMINAL
- TERMINAL
The minus terminal can be marked with a black dot or with an
imprinted ‘-’ sign.
Fig.2 Two terminal snap-in
Fig.3 Mounting hole diagram
Ø 2 ± 0.1 (2 x)
10
± 0.1
Ø D
L + 2 max.
4 ± 0.5
minus pole
marking
Bottom view
TERMINAL
TERMINAL
L
Fig.4 Three terminal snap-in
The negative terminal has TWO pins which are BOTH electrically
connected.
Ø 2 ± 0.1
(2 x)
Ø 2.5
± 0.1
3.3
± 0.1
10
± 0.1
4.75 ± 0.1
The 10 mm spacing of the 2 pin snap-in is used as the base layout
and a third hole is added.
The third hole is closer to the negative primary hole so that
polarization is always maintained, together with added mechanical
stability.
Fig.5 Mounting hole diagram
