058/059 PLL-SI
Vishay BCcomponents Aluminum Capacitors
Power Long Life Snap-In
www.vishay.com For technical questions, contact: [email protected] Document Number: 28342
4 Revision: 18-Aug-08
Note
•
Unless otherwise specified, all electrical values in Tables 2 and 3
apply at T
amb
= 20 °C, P = 86 to 106 kPa, RH = 45 to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 058 series
10 000 µF/25 V; ± 20 %
Nominal case size: Ø 30 x 40 mm
2-terminal snap-in
3-terminal snap-in
Table 2
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz
I
R
rated RMS ripple current at 100 Hz or
≥ 10 kHz and 105 °C
I
L1
max. leakage current after 1 minute at U
R
I
L5
max. leakage current after 5 minutes at U
R
ESR max. equivalent series resistance at 100 Hz
Z max. impedance at 10 kHz
Ordering code: MAL2 058 56103 E3
Former 12NC: 2222 058 56103
Ordering code: MAL2 058 76103 E3
Former 12NC: 2222 058 76103
ELECTRICAL DATA AND ORDERING INFORMATION FOR 058 SERIES (Ø D x L in mm)
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
105 °C
(A)
I
R
≥ 10 kHz
105 °C
(A)
I
L1
1 min
(µA)
I
L5
5 min
(µA)
ESR
100 Hz
(m
Ω)
Z
10 Hz
(m
Ω)
ORDERING CODE
MAL2058.......
2-TERM. 3-TERM.
10
4700 22 x 25 1.95 2.30 286 98 82 57 54472E3 74472E3
6800 22 x 30 2.44 2.88 412 140 61 44 54682E3 74682E3
10 000 25 x 30 2.81 3.32 604 204 54 42 54103E3 74103E3
10 000 22 x 40 3.29 3.88 604 204 43 32 44103E3 24103E3
15 000 30 x 30 3.53 4.17 904 304 42 34 54153E3 74153E3
15 000 25 x 40 3.78 4.46 904 304 38 30 44153E3 24153E3
22 000 30 x 40 4.62 5.45 1324 444 31 25 54223E3 74223E3
22 000 25 x 50 4.68 5.52 1324 444 31 24 44223E3 24223E3
33 000 35 x 40 5.15 6.08 1984 664 30 24 54333E3 74333E3
33 000 30 x 50 5.70 6.73 1984 664 24 21 44333E3 24333E3
47 000 35 x 50 6.23 7.35 2824 944 24 21 54473E3 74473E3
16
3300 22 x 25 1.90 2.24 321 110 86 57 55332E3 75332E3
4700 22 x 30 2.36 2.78 455 154 65 44 55472E3 75472E3
6800 25 x 30 2.75 3.25 657 222 56 42 55682E3 75682E3
6800 22 x 40 3.18 3.75 657 222 46 32 45682E3 25682E3
10 000 30 x 30 3.44 4.06 964 324 44 34 55103E3 75103E3
10 000 25 x 40 3.66 4.32 964 324 40 30 45103E3 25103E3
15 000 30 x 40 4.55 5.37 1444 484 32 25 55153E3 75153E3
15 000 25 x 50 4.55 5.37 1444 484 32 24 45153E3 25153E3
22 000 35 x 40 5.07 5.98 2116 708 31 24 55223E3 75223E3
22 000 30 x 50 5.67 6.69 2116 708 25 21 45223E3 25223E3
33 000 35 x 50 6.23 7.35 3172 1060 25 21 55333E3 75333E3
25
2200 22 x 25 1.76 2.08 334 114 100 57 56222E3 76222E3
3300 22 x 30 2.23 2.63 499 169 73 44 56332E3 76332E3
4700 25 x 30 2.60 3.07 709 239 62 42 56472E3 76472E3
4700 22 x 40 3.00 3.54 709 239 52 32 46472E3 26472E3
6800 30 x 30 3.26 3.85 1024 344 49 34 56682E3 76682E3
6800 25 x 40 3.49 4.12 1024 344 44 30 46682E3 26682E3
10 000 30 x 40 4.37 5.16 1504 504 35 25 56103E3 76103E3
10 000 25 x 50 4.37 5.16 1504 504 35 24 46103E3 26103E3
15 000 35 x 40 4.91 5.79 2254 754 33 24 56153E3 76153E3
15 000 30 x 50 5.43 6.41 2254 754 27 21 46153E3 26153E3
22 000 35 x 50 6.07 7.16 3304 1104 27 21 56223E3 76223E3
40
1500 22 x 25 1.65 2.01 364 124 114 65 57152E3 77152E3
2200 22 x 30 2.04 2.49 532 180 87 50 57222E3 77222E3
3300 25 x 30 2.43 2.99 796 268 71 45 57332E3 77332E3
3300 22 x 40 2.78 3.39 796 268 60 37 47332E3 27332E3
4700 30 x 30 2.96 3.61 1132 380 59 40 57472E3 77472E3
4700 25 x 40 3.26 3.90 1132 380 51 32 47472E3 27472E3
6800 30 x 40 3.94 4.81 1636 548 42 29 57682E3 77682E3
6800 25 x 50 4.10 5.00 1636 548 39 26 47682E3 27682E3
10 000 35 x 40 4.18 5.10 2404 804 46 29 57103E3 77103E3
10 000 30 x 50 4.98 6.08 2404 804 36 24 47103E3 27103E3
15 000 35 x 50 5.21 6.36 3604 1204 36 24 57153E3 77153E3
