058/059 PLL-SI
Vishay BCcomponents Aluminum Capacitors
Power Long Life Snap-In
www.vishay.com For technical questions, contact: [email protected] Document Number: 28342
10 Revision: 18-Aug-08
Table 5
TEST PROCEDURES AND REQUIREMENTS
TEST PROCEDURE
(quick reference)
REQUIREMENTS
NAME OF TEST REFERENCE
Endurance IEC 60384-4/
EN130300
subclause 4.13 T
amb
= 105 °C; U
R
applied;
≤ 50 V types: 2000 hours;
≥ 63 V types: 5000 hours
U
R
≤ 100 V; ΔC/C: ± 15 %
U
R
> 100 V; ΔC/C: ± 10 %
ESR
≤ 1.3 x spec. limit
Z ≤ 2 x spec. limit
I
L5
≤ spec. limit
Useful life CECC 30301
subclause 1.8.1 T
amb
= 105
°C; U
R
and I
R
applied;
≤ 50 V types: 5000 hours;
≥ 63 V types: 10 000 hours
U
R
≤ 100 V; ΔC/C: ± 45 %
U
R
> 100 V; ΔC/C: ± 30 %
ESR
≤ 3 x spec. limit
Z ≤ 3 x spec. limit
I
L5
≤ spec. limit
no short or open circuit,
no visible damage
total failure percentage;
U
R
> 100 V: ≤ 3 %
Shelf life
(storage at
high temperature) IEC 60384-4/
EN130300
subclause 4.17 T
amb
= 105
°C; no voltage applied;
500 hours
After test: U
R
to be applied for 30 minutes
24 hours to 48 hours before measurement
ΔC/C: ± 10 %
ESR
≤ 1.2 x spec. limit
I
L5
≤ 2 x spec. limit
