2.6.3 How to make TR-151 enter motion mode by SMS?
You could send a SMS to ask TR-151 to enter motion mode. Under motion mode, in addition
to the regular report interval, TR-151 will send out the motion report when it senses vibration.
If you’d like to continually get the location information of the vehicle installed with TR-151, you
could make TR-151 enter motion mode.
The format of SMS is following as:
?16,IMEI,Report_method,Regular_Report_Interval,Vibration_Report_interval,Sensitivity,Moti
on_Return_Phone_number,Return_phone_number!
The table below explains the content of the SMS
Format Description
? Start sign
16 Function code
IMEI IMEI code of the TR-151
The method of sending the location information
1: SMS
Report Method
2: GPRS
3: SMS & GPRS
The regular report interval of motion mode. The unit is minute. The
range is 30-1440 minute.
Regular Report Interval
The report interval when TR-151 senses vibration. The unit is
second. The range is 5-86400 second.
Motion Report Interval
The number of vibration which activates TR-151 to send motion
report. The value range is 1~255. The larger the number is, the less
sensitive the device is.
Sensitivity
Motion_Return_Phone_Number The phone number for receiving location report
Return_Phone_Number The phone number for receiving return message.
! End sign
TR-151 will send an SMS whose format is“?16,IMEI,OK!” to the return phone number to
confirm it has received the request.
According to the regular report interval, TR-151 will send the regular report like
“?IMEI, 17 ,GPS_Fix,Date,Time,Longitude,Latitude,Altitude,Speed,Heading,Number_of_Satelli
tes_In_Use,HDOP! ” . (For details of the data, please refer to SMS Return Format )
When TR-151 senses vibration over the value of the sensitivity for the first time, it will send the
motion report like
“?IMEI, 24 ,GPS_Fix,Date,Time,Longitude,Latitude,Altitude,Speed,Heading,Number_of_Satelli
tes_In_Use,HDOP! ” . (For details of the data, please refer to SMS Return Format )
When TR-151 senses vibration over the value of the sensitivity following the first time of
49
