Jul. 2005
MITSUBISHI HVIGBT MODULES
CM400HG-66H
HIGH POWER SWITCHING USE
INSULATED TYPE
● I
C ................................................................... 400A
● V
CES ....................................................... 3300V
● High Insulated Type
● 1-element in a Pack
● AISiC Baseplate
APPLICATION
Traction drives, High Reliability Converters / Inverters, DC choppers
CM400HG-66H
OUTLINE DRAWING & CIRCUIT DIAGRAM Dimensions in mm
3rd-Version HVIGBT (High Voltage Insulated Gate Bipolar Transistor) Modules
HVIGBT (High Voltage Insulated Gate Bipolar Transistor) Modules
17
± 0.1
140
± 0.5
124
± 0.25
44
± 0.3
73 ± 0.5
57 ± 0.25
2
1
E G C
16.2 ± 0.3
2 - M8 NUTS
4 - φ 7 MOUNTING HOLES
29.7
36
C E
G
(1)
(2) C
E
CIRCUIT DIAGRAM
40.4
± 0.5
TAB # 110, T = 0.5
2.8
17.4 ± 0.3
22 ± 0.3
41 ± 0.5
LABEL
5
21.6 ± 0.3 12.9 ± 0.3
5.8
5
± 0.15 36.2
48
+1.0 0
screwing depth
min. 16.5
screwing depth
min. 4
