050/052 PED-PW
Vishay BCcomponents Aluminum Capacitors
Power Eurodin Printed Wiring
www.vishay.com For technical questions, contact: [email protected] Document Number: 28345
130 Revision: 10-Mar-09
Table 3
63
1000 25 x 30 1.8 3.4 0.38 0.13 122 74 18102E3 58102E3
1500 25 x 40 2.5 4.7 0.57 0.19 83 54 18152E3 58152E3
2200 30 x 40 3.1 5.9 0.83 0.28 57 41 18222E3 58222E3
3300 35 x 40 3.6 6.8 1.25 0.42 48 35 18332E3 58332E3
4700 35 x 50 4.4 8.3 1.78 0.60 36 27 18472E3 58472E3
4700 40 x 40 3.8 7.2 1.78 0.60 45 33 not available 48472E3
6800 40 x 50 4.7 8.9 2.57 0.86 35 27 18682E3 58682E3
10 000 40 x 70 6.2 11.8 3.78 1.26 25 20 18103E3 58103E3
15 000 40 x 100 8.5 16.1 5.67 1.89 18 16 18153E3 58153E3
100
470 25 x 30 1.4 2.7 0.28 0.10 247 172 19471E3 59471E3
680 25 x 40 1.9 3.6 0.41 0.14 170 116 19681E3 59681E3
1000 30 x 40 2.5 4.7 0.60 0.20 123 88 19102E3 59102E3
1500 35 x 40 3.1 5.8 0.90 0.30 94 71 19152E3 59152E3
2200 35 x 50 3.9 7.4 1.32 0.44 69 55 19222E3 59222E3
2200 40 x 40 3.6 6.8 1.32 0.44 81 65 not available 49222E3
3300 40 x 50 4.6 8.7 1.98 0.66 59 48 19332E3 59332E3
4700 40 x 70 6.2 11.7 2.82 0.94 42 36 19472E3 59472E3
6800 40 x 100 8.2 15.5 4.08 1.36 32 28 19682E3 59682E3
ELECTRICAL DATA AND ORDERING INFORMATION FOR 050 SERIES
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
R
20 kHz
70 °C
(A)
I
L1
1 min
(mA)
I
L5
5 min
(mA)
ESR
100 Hz
(m Ω)
Z
10 kHz
(m Ω)
ORDERING
CODE SL
MAL2050.......
ORDERING
CODE PW
MAL2050.......
ELECTRICAL DATA AND ORDERING INFORMATION FOR 052 SERIES
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
R
20 kHz
70 °C
(A)
I
L1
1 min
(mA)
I
L5
5 min
(mA)
ESR
100 Hz
(m
Ω)
Z
10 kHz
(m
Ω)
ORDERING
CODE
MAL2052.......
250
100 25 x 30 0.6 1.15 0.15 0.05 1800 1300 53101E3
150 25 x 40 0.8 1.5 0.23 0.08 1100 850 53151E3
220 30 x 40 1.0 1.9 0.33 0.11 750 550 53221E3
330 35 x 40 1.4 2.65 0.49 0.17 500 400 53331E3
470 35 x 50 1.8 3.4 0.70 0.24 360 290 53471E3
470 40 x 40 1.8 3.4 0.70 0.24 420 350 43471E3
680 40 x 50 2.3 4.4 1.02 0.34 250 190 53681E3
1000 40 x 70 3.0 5.7 1.50 0.50 170 140 53102E3
385
47 25 x 30 0.5 0.94 0.11 0.04 2370 1550 58479E3
68 25 x 40 0.67 1.27 0.16 0.06 1640 1100 58689E3
100 30 x 40 0.84 1.59 0.23 0.08 1275 950 58101E3
150 35 x 40 1.13 2.14 0.34 0.11 850 635 58151E3
220 35 x 50 1.48 2.8 0.50 0.17 580 430 58221E3
220 40 x 40 1.48 2.8 0.50 0.17 580 430 48221E3
330 40 x 50 1.97 3.73 0.75 0.25 385 300 58331E3
470 40 x 70 2.7 5.11 1.06 0.36 270 215 58471E3
400
47 25 x 30 0.47 0.89 0.11 0.04 2700 2125 56479E3
68 25 x 40 0.63 1.29 0.16 0.06 1875 1470 56689E3
100 30 x 40 0.84 1.59 0.24 0.08 1275 1000 56101E3
150 35 x 40 1.13 2.14 0.36 0.12 850 665 56151E3
220 35 x 50 1.41 2.67 0.52 0.17 650 450 56221E3
220 40 x 40 1.41 2.67 0.52 0.17 650 450 46221E3
330 40 x 50 1.86 3.52 0.79 0.26 435 315 56331E3
470 40 x 70 2.54 4.81 1.12 0.37 305 225 56471E3
680 40 x 100 3.56 6.75 1.63 0.54 210 155 56681E3
