050/052 PED-PW
Aluminum Capacitors
Power Eurodin Printed Wiring
Vishay BCcomponents
Note
• Unless otherwise specified, all electrical values in tables 2 and 3
apply at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 050 series
10 000 µF/25 V; - 10/+ 30 %
Nominal case size:
Ø 35 x 50 mm; PW version
Table 2
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz
I
R
rated RMS ripple current at 100 Hz,
85 °C or at 20 kHz, 70 °C
I
L1
max. leakage current after 1 minute at U
R
I
L5
max. leakage current after 5 minutes at U
R
ESR max. equivalent series resistance at 100 Hz
Z max. impedance at 10 kHz
Ordering code: MAL2 050 56103 E3
Former 12NC: 2222 050 56103
ELECTRICAL DATA AND ORDERING INFORMATION FOR 050 SERIES
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
85 °C
(A)
I
R
20 kHz
70 °C
(A)
I
L1
1 min
(mA)
I
L5
5 min
(mA)
ESR
100 Hz
(m Ω)
Z
10 kHz
(m Ω)
ORDERING
CODE SL
MAL2050.......
ORDERING
CODE PW
MAL2050.......
10
4700 25 x 30 2.4 4.6 0.28 0.10 74 50 14472E3 54472E3
6800 25 x 40 3.2 6.1 0.41 0.14 51 37 14682E3 54682E3
10 000 30 x 40 3.8 7.2 0.60 0.20 39 29 14103E3 54103E3
15 000 35 x 40 4.1 7.8 0.90 0.30 35 26 14153E3 54153E3
22 000 35 x 50 5.0 9.5 1.32 0.44 27 21 14223E3 54223E3
22 000 40 x 40 4.2 8.0 1.32 0.44 36 27 not available 44223E3
33 000 40 x 50 5.0 9.5 1.98 0.66 29 22 14333E3 54333E3
47 000 40 x 70 6.8 12.9 2.82 0.94 20 17 14473E3 54473E3
68 000 40 x 100 9.2 17.5 4.08 1.36 15 14 14683E3 54683E3
16
3300 25 x 30 2.4 4.6 0.32 0.11 75 50 15332E3 55332E3
4700 25 x 40 3.1 5.9 0.45 0.15 52 37 15472E3 55472E3
6800 30 x 40 3.7 7.0 0.65 0.22 40 30 15682E3 55682E3
10 000 35 x 40 4.1 7.8 0.96 0.32 36 27 15103E3 55103E3
15 000 35 x 50 5.0 9.5 1.44 0.48 28 21 15153E3 55153E3
15 000 40 x 40 4.2 8.0 1.44 0.48 36 27 not available 45153E3
22 000 40 x 50 5.0 9.5 2.12 0.71 29 22 15223E3 55223E3
33 000 40 x 70 6.7 12.7 3.17 1.06 20 17 15333E3 55333E3
47 000 40 x 100 9.1 17.3 4.51 1.51 15 14 15473E3 55473E3
25
2200 25 x 30 2.3 4.4 0.33 0.11 78 52 16222E3 56222E3
3300 25 x 40 3.1 5.9 0.49 0.17 53 38 16332E3 56332E3
4700 30 x 40 3.7 7.0 0.70 0.24 42 31 16472E3 56472E3
6800 35 x 40 4.1 7.8 1.02 0.34 37 28 16682E3 56682E3
10 000 35 x 50 5.0 9.5 1.50 0.50 28 21 16103E3 56103E3
10 000 40 x 40 4.2 8.0 1.50 0.50 36 27 not available 46103E3
15 000 40 x 50 5.0 9.5 2.25 0.75 29 22 16153E3 56153E3
22 000 40 x 70 6.8 12.9 3.30 1.10 20 17 16223E3 56223E3
33 000 40 x 100 9.2 17.5 4.95 1.65 15 14 16333E3 56333E3
1500 25 x 30 2.0 3.8 0.36 0.12 112 68 17152E3 57152E3
2200 25 x 40 2.7 5.1 0.53 0.18 76 51 17222E3 57222E3
3300 30 x 40 3.3 6.3 0.79 0.27 57 41 17332E3 57332E3
4700 35 x 40 3.8 7.2 1.13 0.38 48 35 17472E3 57472E3
40 6800 35 x 50 4.7 8.9 1.64 0.55 36 27 17682E3 57682E3
6800 40 x 40 4.1 7.8 1.64 0.55 45 33 not available 47682E3
10 000 40 x 50 4.9 9.3 2.40 0.80 35 27 17103E3 57103E3
15 000 40 x 70 6.6 12.5 3.60 1.20 25 20 17153E3 57153E3
22 000 40 x 100 9.0 17.1 5.28 1.76 18 16 17223E3 57223E3
