Document Number: 93532 For technical questions, contact: [email protected] www.vishay.com
Revision: 01-Oct-08 1
Standard Recovery Diodes
Generation 2 DO-5 (Stud Version), 95 A
95PF(R)...(W) Series
Vishay High Power Products
FEATURES
• High surge current capability
• Designed for a wide range of applications
• Stud cathode and stud anode version
• Wire version available
• Low thermal resistance
• UL approval pending
• RoHS compliant
• Designed and qualified for multiple level
TYPICAL APPLICATIONS
• Battery charges
• Converters
• Power supplies
• Machine tool controls
• Welding
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
95 A
DO-203AB (DO-5)
95PF(R)... 95PF(R)...W
DO-203AB (DO-5)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
F(AV)
95 A
T
C
140 °C
I
F(RMS)
149 A
I
FSM
50 Hz 2000
A
60 Hz 2090
I 2 t
50 Hz 20 000
A 2 s
60 Hz 18 180
V
RRM
Range 400 to 1200 V
T
J
- 55 to 180 °C
VOLTAGE RATINGS
TYPE
NUMBER VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= 150 °C
mA
95PF(R)...(W)
40 400 500
9 80 800 960
120 1200 1440
