113CNQ100A Series
Bulletin PD-20631 rev. B 02/03
I
F(AV)
Max. Average Forward
(Per Leg)
55
A
50% duty cycle @ T
C
= 150 °C, rectangular wave form
Current * See Fig. 5
(Per Device)
110
I
FSM
Max. Peak One Cycle Non-Repetitive
7000
5µs Sine or 3µs Rect. pulse
Surge Current (Per Leg) * See Fig. 7
720
10ms Sine or 6ms Rect. pulse
E
AS
Non-Repetitive Avalanche Energy
15
mJ
T
J
= 25 °C, I
AS
= 1 Amps, L = 30 mH
(Per Leg)
I
AR
Repetitive Avalanche Current
1
A
Current decaying linearly to zero in 1 µsec
(Per Leg)
Frequency limited by T
J
max. V
A
= 1.5 x V
R
typical
T
J
Max. Junction Temperature Range
-55 to 175
°C
T
stg
Max. Storage Temperature Range
-55 to 175
°C
R
thJC
Max. Thermal Resistance Junction
0.5
°C/W DC operation
* See Fig. 4
to Case (Per Leg)
R
thJC
Max. Thermal Resistance Junction
0.25
°C/W DC operation
to Case (Per Package)
R
thCS
Typical Thermal Resistance, Case
0.30
°C/W Mounting surface , smooth and greased
to Heatsink (D61-8 Only)
Device flatness < 5mls
wt
Approximate Weight
7.8 (0.28)
g (oz.)
T
Mounting Torque
Min.
12 (10)
(*)
(D61-8 Only)
Max.
24 (20)
Thermal-Mechanical Specifications
Kg-cm
(Ibf-in)
V
FM
Max. Forward Voltage Drop
0.81
V
@ 55A
(Per Leg) * See Fig. 1
(1)
1.00
V
@ 110A
0.66
V
@ 55A
0.79
V
@ 110A
I
RM
Max. Reverse Leakage Current
1.0
mA
T
J
= 25 °C
(Per Leg) * See Fig. 2
(1)
32
mA
T
J
= 125 °C
C
T
Max. Junction Capacitance(Per Leg)
1960
pF
V
R
= 5V
DC
(test signal range 100Khz to 1Mhz) 25°C
L
S
Typical Series Inductance (Per Leg)
5.5
nH
Measured lead to lead 5mm from package body
dv/dt Max. Voltage Rate of Change
10000
V/ µs
(Rated V
R
)
T
J
= 25 °C
T
J
= 125 °C
Electrical Specifications
(1) Pulse Width < 300µs, Duty Cycle <2%
V
R
= rated V
R
Absolute Maximum Ratings
Following any rated
load condition and with
rated V
RRM
applied
Parameters
113CNQ Units
Conditions
A
Part number
113CNQ100A
V
R
Max. DC Reverse Voltage (V)
V
RWM
Max. Working Peak Reverse Voltage (V)
Parameters
113CNQ Units
Conditions
Parameters
113CNQ Units
Conditions
Voltage Ratings
100
