135 RLI
Vishay BCcomponents Aluminum Capacitors
Radial Low Impedance
NOT
F
OR
N
E
W DES
IG
NS
Note
1. Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20 °C, P = 86 to 106 kPa, RH = 45 to 75%.
ORDERING EXAMPLE*
Electrolytic capacitor 135 series
1000
μF/16V; ±20%
Nominal case size:
∅10 × 30 mm; Form CB
Catalog number: 2222 135 65102
* To ensure delivery of lead (Pb)-free parts during the
transition period, please contact your Vishay sales agent.
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 120 Hz, tolerance
± 20%
I
R
rated RMS ripple current at 100 kHz, 105 °C
I
L2
max. leakage current after 2 minutes at U
R
Tan δ max. dissipation factor at 120 Hz
Z max. impedance at 100 kHz
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
120 Hz
(
μF)
NOMINAL
CASE SIZE
∅D × L
(mm)
I
R
100 kHz
105
°C
(mA)
I
L2
2 min
(
μA)
Tan
δ
120 Hz
Z
100 kHz
(
Ω)
CATALOG NUMBER 2222 135 .....
BULK PACKAGING
TAPED
LONG LEADS CUT LEADS
FORM CA
F
(mm)
FORM CB
F
(mm)
FORM
TFA
F
(mm)
6.3 470 10
Ч 12
510 30 0.22 0.28 53471 5.0 63471 5.0 33471 5.0
680 10 Ч 16 640 43 0.22 0.22 53681 5.0 63681 5.0 33681 5.0
2200 12.5
Ч 20
1100 140 0.24 0.089 53222 5.0 63222 5.0 33222 5.0
6800 16 Ч 31 1800 430 0.32 0.055 53682 7.5 63682 7.5 33682 7.5
10000 18
Ч 31
2000 630 0.40 0.047 53103 7.5 63103 7.5
− −
10 470 8 Ч 15 500 47 0.19 0.24 54471 3.5 84471 3.5 34471 5.0
1000 12.5
Ч 16
970 100 0.19 0.12 54102 5.0 64102 5.0 34102 5.0
1500 10 Ч 30 1200 150 0.19 0.093 54152 5.0 64152 5.0 − −
2200 12.5
Ч 25
1300 220 0.21 0.073 54222 5.0 64222 5.0 34222 5.0
2200 18 Ч 15 1300 220 0.21 0.080 90001 7.5 90002 7.5 − −
3300 12.5
Ч 35
1800 330 0.23 0.052 54332 5.0 64332 5.0
− −
3300 16 Ч 20 1400 330 0.23 0.075 90025 7.5 90026 7.5 90042 7.5
4700 16
Ч 31
1800 470 0.25 0.054 54472 7.5 64472 7.5 34472 7.5
4700 18 Ч 25 1800 470 0.25 0.053 90003 7.5 90004 7.5 − −
6800 16
Ч 35
2000 680 0.29 0.046 54682 7.5 64682 7.5
− −
10000 18 Ч 40 2500 1000 0.37 0.037 54103 7.5 64103 7.5 − −
16 220 8
Ч 12
400 35 0.16 0.33 55221 3.5 85221 3.5 35221 5.0
330 8 Ч 15 500 53 0.16 0.23 55331 3.5 85331 3.5 35331 5.0
470 8
Ч 20
650 75 0.16 0.18 55471 3.5 85471 3.5 35471 5.0
680 10 Ч 20 860 110 0.16 0.14 55681 5.0 65681 5.0 35681 5.0
1000 10
Ч 30
1200 160 0.16 0.091 55102 5.0 65102 5.0
− −
1500 12.5
Ч 25
1300 240 0.16 0.072 55152 5.0 65152 5.0 35152 5.0
2200 12.5
Ч 31
1500 350 0.18 0.063 55222 5.0 65222 5.0
− −
2200 16 Ч 20 1400 350 0.18 0.073 90007 7.5 90008 7.5 90043 7.5
4700 16
Ч 35
2000 750 0.22 0.046 55472 7.5 65472 7.5
− −
4700 18 Ч 31 2000 750 0.22 0.046 90009 7.5 90011 7.5 − −
6800 18
Ч 35
2200 1100 0.26 0.040 55682 7.5 65682 7.5
− −
