1N1183, 1N3765, 1N1183A, 1N2128A Series
Vishay High Power Products
Power Silicon Rectifier Diodes,
35 A/40 A/60 A
Notes
(1)
JEDEC registered values
(2)
I
2
t for time t
x
= I
2
√t x √t
x
FORWARD CONDUCTION
PARAMETER
SYMBOL
TEST CONDITIONS
1N1183
1N3765 1N1183A 1N2128A
UNITS
Maximum average forward current
at case temperature
I
F(AV)
1-phase operation,
180° sinusoidal conduction
35
(1)
35
(1)
40
(1)
60
(1)
A
140
(1)
140
(1)
150
(1)
140
(1)
°C
Maximum peak one cycle
non-repetitive surge current
I
FSM
Half cycle 50 Hz
sine wave or 6 ms
rectangular pulse
Following any
rated load
condition and
with rated
V
RRM
applied
480
380
765
860
A
Half cycle 60 Hz
sine wave or 5 ms
rectangular pulse
500
(1)
400
(1)
800
(1)
900
(1)
Half cycle 50 Hz
sine wave or 6 ms
rectangular pulse
Following any
rated load
condition and
with ½ V
RRM
applied following
surge = 0
570
455
910
1000
Half cycle 60 Hz
sine wave or 5 ms
rectangular pulse
595
475
950
1050
Maximum I
2
t for fusing
I
2
t
t = 10 ms
With rated V
RRM
applied following
surge, initial
T
J
= T
J
maximum
1140
730
2900
3700
A
2
s
t = 8.3 ms
1040
670
2650
3400
Maximum I
2
t for individual
device fusing
t = 10 ms
With V
RRM
= 0
following surge,
initial T
J
=
T
J
maximum
1610
1030
4150
5250
t = 8.3 ms
1470
940
3750
4750
Maximum I
2
√t for individual
device fusing
I
2
√t
(2)
t = 0.1 to 10 ms,
V
RRM
= 0 following surge
16 100
10 300
41 500
52 500
A
2
√s
Maximum peak forward voltage
at maximum forward current (I
FM
)
V
FM
T
J
= 25 °C
1.7
(1)
1.8
(1)
1.3
(1)
1.3
(1)
V
110
110
126
188
A
Maximum average
reverse current
V
RRM
= 700
I
R(AV)
Maximum rated I
F(AV)
and T
C
-
5.0
(1)
-
-
mA
V
RRM
= 800
-
4.0
(1)
-
-
V
RRM
= 900
-
3.0
(1)
-
-
V
RRM
= 1000
-
2.0
(1)
-
-
Maximum rated I
F(AV)
, V
RRM
and T
C
10
(1)
-
2.5
(1)
10
(1)
