Document Number: 93223 For technical questions, contact: [email protected] www.vishay.com
Revision: 29-Apr-10 7
20MT060KF
"Full Bridge" IGBT MTP
(Ultrafast NPT IGBT), 20 A
Vishay High Power Products
Fig. C.T.1 - Gate Charge Circuit (Turn-Off)
Fig. C.T.2 - RBSOA Circuit
Fig. C.T.3 - S.C. SOA Circuit
Fig. C.T.4 - Switching Loss Circuit
ORDERING INFORMATION TABLE
1 K
V
CC
D.U.T.
0
L
+
-
L
R
g
80 V
D.U.T
1000 V
+
-
D
C
Driver
D.U.T.
900 V
+
-
L
R
g
V
CC
Diode clamp/
D.U.T.
D.U.T./
driver
- 5 V
- +
+
-
Device code
5 1 3 2 4
1
2
3
4
5
- Current rating (20 = 20 A)
- Essential part number
- Voltage code (060 = 600 V)
- Speed/type (K = Ultrafast IGBT)
- Circuit configuration (F = Full bridge)
20 MT 060 K F
