D-14
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CS240610, CS241210
Fast Recovery Single Diode Modules
100 Amperes/600-1200 Volts
Absolute Maximum Ratings
Characteristics Symbol CS240610 CS241210 Units
Peak Reverse Blocking Voltage VRRM 600 1200 Volts
Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms VRSM 720 1350 Volts
DC Reverse Blocking Voltage VR(DC) 480 960 Volts
DC Current, TC = 75°C IF(DC) 100 100 Amperes
Peak One-Cycle Surge (Non-Repetitive) On-State Current (60Hz) IFSM 2000 2000 Amperes
Peak One-Cycle Surge (Non-Repetitive) On-State Current (50Hz) IFSM 1825 1825 Amperes
I2t (for Fusing), 8.3 milliseconds I2t 16700 16700 A2sec
Storage Temperature TSTG -40 to 125 -40 to 125 °C
Operating Temperature Tj -40 to 150 -40 to 150 °C
Maximum Mounting Torque M5 Mounting Screw — 17 17 in.-lb.
Maximum Mounting Torque M4 Terminal Screw — 12 12 in.-lb.
Module Weight (Typical) — 90 90 Grams
V Isolation VRMS 2500 2500 Volts
