VS-GT300FD060N
www.vishay.com
Vishay Semiconductors
Revision: 15-Oct-12 3 Document Number: 93569
For technical questions within your region: [email protected] , [email protected] , [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Q1 - Q2 - Q3 - Q4 TRENCH IGBT
Turn-on switching loss E
ON
I
C
= 300 A
V
CC
= 300 V
V
GE
= 15 V
R
g
= 22

L = 500 μH
T
J
= 125 °C
- 10.7 -
mJ Turn-off switching loss E
OFF
- 15.6 -
Total switching loss E
TOT
- 26.3 -
Turn-on delay time t
d(on)
- 840 -
ns
Rise time t
r
- 279 -
Turn-off delay time t
d(off)
- 566 -
Fall time t
f
- 129 -
Input capacitance C
ies V
GE
= 0 V
V
CC
= 30 V
f = 1 MHz
- 23.3 -
nF Output capacitance C
oes
- 1.7 -
Reverse transfer capacitance C
res
- 0.7 -
Reverse bias safe operating area RBSOA
T
J
= 175 °C, I
C
= 650 A
V
CC
= 270 V, V
P
= 600 V
R
g
= 22
, V
GE
= 15 V to 0 V
Short circuit safe operating area SCSOA
V
CC
= 400 V, V
p
= 600 V
R
g
= 10
, V
GE
= 15 V to 0 V
- - 5.0 μs
D5 - D6 CLAMPING DIODE
Diode reverse recovery time t
rr V
R
= 200 V
I
F
= 50 A
dl/dt = 500 A/μs
- 105 - ns
Diode peak reverse current I
rr
- 13.5 - A
Diode recovery charge Q
rr
- 712 - nC
Diode reverse recovery time t
rr V
R
= 200 V
I
F
= 50 A
dl/dt = 500 A/μs, T
J
= 125 °C
- 166 - ns
Diode peak reverse current I
rr
- 24.5 - A
Diode recovery charge Q
rr
- 2050 - nC
D1 - D2 - D3 - D4 AP DIODE
Diode reverse recovery time t
rr V
R
= 200 V
I
F
= 50 A
dl/dt = 500 A/μs
- 105 - ns
Diode peak reverse current I
rr
- 13.5 - A
Diode recovery charge Q
rr
- 712 - nC
Diode reverse recovery time t
rr V
R
= 200 V
I
F
= 50 A
dl/dt = 500 A/μs, T
J
= 125 °C
- 166 - ns
Diode peak reverse current I
rr
- 24.5 - A
Diode recovery charge Q
rr
- 2050 - nC
THERMAL AND MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL MIN. TYP. MAX. UNITS
Junction to case IGBT thermal resistance (per switch)
R
thJC
- - 0.12
°C/W Junction to case diode thermal resistance (per diode) - - 0.3
Case to sink, flat, greased surface (per module) R
thCS
- 0.05 -
Mounting torque, case to heatsink: M6 screw 4 - 6
Nm
Mounting torque, case to terminal: 1, 2, 3, 4: M5 screw 2 - 4
Weight - 270 - g
SWITCHING CHARACTERISTICS (T
J
= 25 °C unless otherwise noted)
