Electrical Characteristics, Tj=25°C unless otherwise specified
Rating
Characteristic Symbol Test Conditions min typ max Units
Repetitive Peak Reverse
Leakage Current I
RRM
Tj=175°C, V
RRM
=Rated 100 150 ma
Peak On-State Voltage V
FM
Tj=25°C, I
FM
=3000A 1.17 V
V
FM
Model, Low Level V
0
Tj=175°C 0.75 V
VFM = V
O
+ r• I
FM
r 15% I
FM
- π•I
FM
0.133 mΩ
V
FM
Model, High Level V
0
Tj=175°C 0.88 V
VFM = V
O
+ r• I
FM
r π•I
FM
- I
FSM
0.122 mΩ
V
FM
Model, 4-Term A Tj=175°C 0.597
V
FM
= A + B•Ln(I
FM
) + B 15%I
FM
- I
FSM
0.0131
C•(I
FM
) + D•(I
FM
)
½
C 1.153E-04
D 0.00212
Reverse Recovery Time t
RR
Tj=25°C, I
FM
=2000A 30 µs
di
R
/dt = 25 A/µs
Thermal Characteristics
Rating
Page 3
g
Characteristic Symbol Test Conditions min typ max Units
Thermal Resistance
Junction to Case RΘ
jc
Double side cooled 0.010 0.0115 °C/Watt
Case to Sink
RΘ
cs
Double side cooled 0.0015 0.002 °C/Watt
Thermal Impedance Model ZΘ
jc
Double side cooled
ZΘ
jc
(t) =
Σ(A(
N
)•(1-exp(-t/
Tau
(
N
))))
where: N = 1 2 3 4
A(N ) =
1.020E-05 8.786E-04 4.154E-03 6.431E-03
T au(N) =
5.860E-04 1.409E-02 1.814E-01 1.208E+00
