VS-GA200TH60S
www.vishay.com
Vishay Semiconductors
Revision: 17-Sep-12 2 Document Number: 94762
For technical questions within your region: [email protected] , [email protected] , [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
IGBT ELECTRICAL SPECIFICATIONS (T
C
= 25 °C unless otherwise noted)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Collector to emitter breakdown voltage V
(BR)CES
T
J
= 25 °C 600 - -
V Collector to emitter voltage V
CE(on)
V
GE
= 15 V, I
C
= 200 A, T
J
= 25 °C - 1.9 -
V
GE
= 15 V, I
C
= 200 A, T
J
= 125 °C - 2.3 -
Gate to emitter threshold voltage V
GE(th)
V
CE
= V
GE
, I
C
= 0.25 mA, T
J
= 25 °C 3.5 4.5 5.5
Collector cut-off current I
CES
V
CE
= V
CES
, V
GE
= 0 V, T
J
= 25 °C - - 5.0 μA
Gate to emitter leakage current I
GES
V
GE
= V
GES
, V
CE
= 0 V, T
J
= 25 °C - - 400 nA
SWITCHING CHARACTERISTICS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Turn-on delay time t
d(on)
V
CC
= 300 V, I
C
= 200 A, R
g
= 4.7
,
V
GE
= ± 15 V, T
J
= 25 °C
- 106 -
ns
Rise time t
r
- 45 -
Turn-off delay time t
d(off)
- 460 -
Fall time t
f
- 51 -
Turn-on switching loss E
on
- 4.2 -
mJ
Turn-off switching loss E
off
- 9.0 -
Turn-on delay time t
d(on)
V
CC
= 300 V, I
C
= 200 A, R
g
= 4.7 ,
V
GE
= ± 15 V, T
J
= 125 °C
- 120 -
ns
Rise time t
r
- 68 -
Turn-off delay time t
d(off)
- 510 -
Fall time t
f
- 70 -
Turn-on switching loss E
on
- 5.1 -
mJ
Turn-off switching loss E
off
- 11.3 -
Input capacitance C
ies
V
GE
= 0 V, V
CE
= 25 V, f = 1.0 MHz
- 13.1 -
nF Output capacitance C
oes
- 0.71 -
Reverse transfer capacitance C
res
- 0.38 -
SC data I
SC
t
sc
 10 μs, V
GE
= 15 V, T
J
= 125 °C, 
V
CC
= 300 V, V
CEM
 600 V
- 650 - A
Stray inductance L
CE
- - 20 nH
Module lead resistance, terminal to chip R
CC’+EE’
T
C
= 25 °C - 0.35 - m 
DIODE ELECTRICAL SPECIFICATIONS (T
C
= 25 °C unless otherwise noted)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Diode forward voltage V
F
I
F
= 200 A
T
J
= 25 °C - 1.4 1.6
V
T
J
= 125 °C - 1.6 1.8
Diode reverse recovery charge Q
rr
I
F
= 200 A, V
R
= 300 V, 
dI/dt = - 6000 A/μs,

V
GE
= - 15 V
T
J
= 25 °C - 9 -
μC
T
J
= 125 °C - 16 -
Diode peak reverse recovery current I
rr
T
J
= 25 °C - 140 -
A
T
J
= 125 °C - 165 -
Diode reverse recovery energy E
rec
T
J
= 25 °C - 2.4 -
mJ
T
J
= 125 °C - 4.2 -
