EYZ
Aluminum Capacitors
Power 105 °C Printed Wiring Style
Vishay Roederstein
100
470 25 × 30 1.42 0.28 0.10 240 155 EYZ00AV347L02V
680 25 × 40 1.90 0.41 0.14 167 109 EYZ00AB368L02V
1000 30
× 40
2.48 0.60 0.20 120 79 EYZ00BB410L02V
1500 35
× 40
3.17 0.90 0.30 88 61 EYZ00CB415L02V
2200 35 × 50 3.79 1.32 0.44 72 53 EYZ00CD422L02V
2200 40 × 40 3.79 1.32 0.44 72 53 EYZ00DB422L02V
3300 40
× 50
4.81 1.98 0.66 53 40 EYZ00DD433L02V
4700 40
× 70
6.49 2.82 0.94 38 29 EYZ00DG447L02V
6800 40 × 100 8.80 4.08 1.36 28 21 EYZ00DM468L02V
200
150 25 × 30 0.72 0.18 0.06 950 710 EYZ00AV315S02V
220 25
× 40
0.96 0.26 0.09 650 485 EYZ00AB322S02V
330 30
× 40
1.29 0.40 0.14 442 330 EYZ00BB333S02V
470 35 × 40 1.66 0.57 0.19 321 240 EYZ00CB347S02V
680 35 × 50 2.09 0.82 0.28 237 185 EYZ00CD368S02V
680 40
× 40
2.09 0.82 0.28 237 185 EYZ00DB368S02V
1000 40
× 50
2.71 1.20 0.40 167 133 EYZ00DD410S02V
1500 40 × 70 3.75 1.80 0.60 114 90 EYZ00DG415S02V
2200 40 × 100 5.24 2.64 0.88 79 62 EYZ00DM422S02V
250
100 25
× 30
0.67 0.15 0.05 1060 710 EYZ00AV310N02V
150 25
× 40
0.92 0.22 0.08 710 485 EYZ00AB315N02V
220 30 × 40 1.28 0.33 0.11 492 330 EYZ00BB322N02V
330 35
× 40
1.65 0.49 0.17 325 240 EYZ00CB333N02V
470 35
× 50
2.01 0.70 0.24 256 185 EYZ00CD347N02V
470 40
× 40
2.01 0.70 0.24 256 185 EYZ00DB347N02V
680 40 × 50 2.59 1.02 0.34 182 133 EYZ00DD368N02V
1000 40
× 70
3.58 1.50 0.50 125 90 EYZ00DG410N02V
1500 40
× 100
5.05 2.25 0.75 85 62 EYZ00DM415N02V
385
68 25
× 30
0.61 0.16 0.06 1650 1260 EYZ00AV268R02V
100 25 × 40 0.82 0.23 0.08 1120 855 EYZ00AB310R02V
150 30
× 40
1.10 0.35 0.12 755 580 EYZ00BB315R02V
220 35
× 40
1.44 0.51 0.17 525 405 EYZ00CB322R02V
330 35
× 50
1.84 0.77 0.26 360 280 EYZ00CD333R02V
330 40 × 40 1.84 0.77 0.26 360 280 EYZ00DB333R02V
470 40
× 50
2.37 1.09 0.36 260 205 EYZ00DD347R02V
680 40
× 70
3.24 1.58 0.53 180 140 EYZ00DG368R02V
1000 40 × 100 4.54 2.31 0.78 125 100 EYZ00DM410R02V
400
68 25 × 30 0.39 0.16 0.06 3200 2660 EYZ00AV268X02V
100 25
× 40
0.53 0.24 0.08 2180 1810 EYZ00AB310X02V
150 30
× 40
0.72 0.36 0.12 1460 1210 EYZ00BB315X02V
220 35 × 40 0.94 0.52 0.17 1010 830 EYZ00CB322X02V
330 35 × 50 1.24 0.79 0.26 680 570 EYZ00CD333X02V
330 40
× 40
1.24 0.79 0.26 680 570 EYZ00DB333X02V
470 40
× 50
1.59 1.12 0.37 485 407 EYZ00DD347X02V
680 40 × 70 2.18 1.63 0.54 336 282 EYZ00DG368X02V
1000 40 × 100 3.07 2.40 0.80 230 193 EYZ00DM410X02V
ADDITIONAL ELECTRICAL DATA
PARAMETER CONDITIONS VALUE
Voltage
Surge voltage ≤ 200 V versions U
s
= 1.15
× U
R
≥ 385 V versions U
s
= 1.1
× U
R
Reverse voltage U
rev
≤ 1 V
Current
Leakage current after 1 minute at U
R
I
L1
≤ 0.006 C
R
× U
R
+ 4 µA
after 5 minutes at U
R
I
L5
≤ 0.002 C
R
× U
R
+ 4 µA
Inductance
Equivalent series inductance (ESL) case ∅ D = 25 mm max. 25 nH
case
∅ D = 30 and 35 mm
max. 30 nH
case ∅ D = 40 mm max. 35 nH
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
∅ D × L
(mm)
I
R
100 Hz
105 °C
(A)
I
L1
1 min
(mA)
I
L5
5 min
(mA)
ESR
100 Hz
(m Ω)
Z
10 kHz
(m Ω)
CATALOG
NUMBER
