Document Number: 25127 For technical questions contact: [email protected] www.vishay.com
Revision: 20-Jul-06 211
EYZ
Not for new design Vishay Roederstein
Aluminum Capacitors
Power 105 °C Printed Wiring Style
FEATURES
• Polarized aluminum electrolytic capacitors,
non-solid electrolyte
• Large types, minimized dimensions, cylindrical
aluminum case, insulated with a blue sleeve
• Provided with keyed polarity
• Very long useful life:
5000 hours at 105 °C
• Low ESR, high ripple current capability
• Temperature range up to 105 °C
• High resistance to shock and vibration
APPLICATIONS
• Computer, telecommunication and industrial systems
• Smoothing and filtering
• Standard and switched mode power supplies
• Energy storage in pulse systems
MARKING
The capacitors are marked (where possible)
with the following information:
• Rated capacitance (in µF)
• Tolerance on rated capacitance, code letter in accordance
with IEC 60062 (M for
± 20 %)
• Rated voltage (in V)
• Date code (YYMM)
• Name of manufacturer
• Code for factory of origin
• Polarity of the terminals and ‘−’ sign to indicate the
negative terminal, visible from the top and/or side of the
capacitor
• Code number
• Climatic category in accordance with IEC 60068
QUICK REFERENCE DATA
DESCRIPTION VALUE
Nominal case size (
∅ D × L in mm)
25
× 30 to 40 × 100
Rated capacitance range
(E6 series), C
R
470 to
150000 µF
68 to
3300 µF
Tolerance on C
R
± 20 %
Rated voltage range, U
R
10 to 100 V 200 to 400 V
Category temperature range
− 40 to + 105 °C
Endurance test at 105 °C 2000 hours
Useful life at 105 °C 5000 hours
Useful life at 40 °C,
1.9
× I
R
applied
150000 hours
Shelf life at 0 V, 105 °C 500 hours
Based on sectional specification IEC 60384-4/EN130300
Climatic category IEC 60068 40/105/56
Component outlines.
.
SELECTION CHART FOR C
R
, U
R
AND RELEVANT NOMINAL CASE SIZES (
∅ D × L in mm)
C
R
(µF)
U
R
(V)
10 16 25 40 63 100
470
− − − − −
25
Ч 30
680 − − − − − 25 Ч 40
1000
− − − −
25
Ч 30
30
Ч 40
1500 − − − − 25 Ч 40 35 Ч 40
2200
− − −
25
Ч 30
30
Ч 40
35
Ч 50
− − − − −
40
Ч 40
3300 − − − 25 Ч 40 35 Ч 40 40 Ч 50
4700
− −
25
Ч 30
30
Ч 40
35
Ч 50
40
Ч 70
− − − −
40
Ч 40 −
6800 − 25 Ч 30 25 Ч 40 35 Ч 40 40 Ч 50 40 Ч 100
10000 25
Ч 30
25
Ч 40
30
Ч 40
35
Ч 50
40
Ч 70 −
− − − 40 Ч 40 − −
15000 25
Ч 40
30
Ч 40
35
Ч 40
40
Ч 50
40
Ч 100 −
22000 30
Ч 40
35
Ч 40
35
Ч 50
40
Ч 70 − −
− − 40 Ч 40 − − −
33000 35
Ч 40
35
Ч 50
40
Ч 50
40
Ч 100 − −
−
40
Ч 40 − − − −
47000 35 Ч 50 40 Ч 50 40 Ч 70 − − −
40
Ч 40 − − − − −
68000 40 Ч 50 40 Ч 70 40 Ч 100 − − −
100000 40 Ч 70 40 Ч 100 − − − −
150000 40
Ч 100 − − − − −
Available
Pb-free
RoHS*
COMPLIANT
*Pb containing terminations are not RoHS compliant, exemptions may apply
