www.vishay.com For technical questions, contact: [email protected] Document Number: 93536
2 Revision: 14-May-08
SD1100C..L Series
Vishay High Power Products Standard Recovery Diodes
(Hockey PUK Version),
1170 A
ELECTRICAL SPECIFICATIONS
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
SD1100C..L
04 400 500
15
08 800 900
12 1200 1300
16 1600 1700
20 2000 2100
25 2500 2600
30 3000 3100
32 3200 3300
FORWARD CONDUCTION
PARAMETER SYMBOL TEST CONDITIONS
SD1100C..L
UNITS
04 to 20 25 to 32
Maximum average forward current
at heatsink temperature
I
F(AV)
180° conduction, half sine wave
Double side (single side) cooled 1170 (600) 910 (420) A
55 (85) 55 (85) °C
Maximum RMS forward current I
F(RMS)
25 °C heatsink temperature double side cooled 2080 1660
A Maximum peak, one-cycle forward,
non-repetitive surge current
I
FSM
t = 10 ms No voltage
reapplied
Sinusoidal half wave,
initial T
J
= T
J
maximum
13 000 10 500
t = 8.3 ms 13 600 11 000
t = 10 ms 100 % V
RRM
reapplied
10 930 8830
t = 8.3 ms 11 450 9250
Maximum I 2 t for fusing I 2 t
t = 10 ms No voltage
reapplied 846 551
kA 2 s
t = 8.3 ms 772 503
t = 10 ms 100 % V
RRM
reapplied
598 390
t = 8.3 ms 546 356
Maximum I 2 √t for fusing
I 2 √t
t = 0.1 to 10 ms, no voltage reapplied 8460 5510 kA 2 √s
Low level value of threshold voltage V
F(TO)1
(16.7 % x
π x I
F(AV)
< I <
π x I
F(AV)
), T
J
= T
J
maximum 0.78 0.84
V
High level value of threshold voltage V
F(TO)2
(I >
π x I
F(AV)
), T
J
= T
J
maximum 0.94 0.88
Low level value of forward
slope resistance
r
f1
(16.7 % x
π x I
F(AV)
< I <
π x I
F(AV)
), T
J
= T
J
maximum 0.35 0.40
m Ω
High level value of forward
slope resistance
r
f2
(I > π x I
F(AV)
), T
J
= T
J
maximum 0.26 0.38
Maximum forward voltage drop V
FM
I
pk
= 1500 A, T
J
= T
J
maximum,
t
p
= 10 ms sinusoidal wave
1.31 1.44 V
