CM600HG-130H
Single IGBTMOD™ HVIGBT Module
600 Amperes/6500 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
2
5/08
Absolute Maximum Ratings, T
j
= 25 °C unless otherwise specified
Ratings
Symbol
CM600HG-130H
Units
Junction Temperature
T
j
-40 to 150
°C
Storage Temperature
T
stg
-40 to 125
°C
Operating Temperature
T
opr
-40 to +125
°C
Collector-Emitter Voltage (V
GE
= 0V)
V
CES
6500
Volts
Gate-Emitter Voltage (V
CE
= 0V)
V
GES
±20
Volts
Collector Current (DC, T
c
= 80°C)
I
C
600
Amperes
Peak Collector Current (Pulse)
I
CM
1200*
Amperes
Emitter Current** (T
c
= 25°C)
I
E
600
Amperes
Emitter Surge Current** (Pulse)
I
EM
1200*
Amperes
Maximum Collector Dissipation (T
c
= 25°C, IGBT Part, T
j(max)
≤ 125°C)
P
C
8900
Watts
Partial Discharge (V
1
= 6900 V
rms
, V
2
= 5100 V
rms
, 60 Hz (Acc. to IEC 1287))
Q
pd
10
pC
Max. Mounting Torque M8 Main Terminal Screws
–
133
in-lb
Max. Mounting Torque M6 Mounting Screws
–
53
in-lb
Max. Mounting Torque M4 Auxiliary Terminal Screws
–
17
in-lb
Module Weight (Typical)
–
1.35
kg
Isolation Voltage (Charged Part to Baseplate, AC 60Hz 1 min.)
V
iso
10200
Volts
Maximum Turn-Off Switching Current (V
CC
≤ 4500V, V
GE
= ±15V, T
j
= 125°C)
–
1200
Amperes
Short Circuit Capability, Maximum Pulse Width (V
CC
≤ 4500V, V
GE
= ±15V, T
j
= 125°C)
–
10
μ
s
Maximum Reverse Recovery Instantaneous Power
–
3600
kW
(V
CC
≤ 4500V, di
e
/dt
≤ 3000A/
μ
s, T
j
= 125°C)
* Pulse width and repetition rate should be such that device junction temperature (T
j
) does not exceed T
j(oprmax)
rating (125°C).
**Represents characteristics of the anti-parallel, emitter-to-collector free-wheel diode (FWDi).
