Single IGBTMOD™
HVIGBT Module
600 Amperes/6500 Volts
CM600HG-130H
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
1
5/08
H
G
F
M8 NUTS
(6 TYP.)
Q(8 TYP.)
M4 NUTS
(3 TYP.)
L
M
C
N
P
C
C
C
E
C
G
E
E
E
F
D
D
A
E
B
D
C
C
C
E
E
E
E
G
C
J
K
K
Outline Drawing and Circuit Diagram
Dimensions
Inches
Millimeters
A
7.48
190.0
B
5.51
140.0
C
1.89
48.0
D
2.24
57.0
E
4.88
124.0
F
0.87
22.0
G
0.47
12.0
H
0.55
14.0
Description:
Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of one IGBT Transistor in a
reverse-connected super-fast
recovery free-wheel diode.
All components and interconnects
are isolated from the heat sinking
baseplate, offering simplified
system assembly and thermal
management.
Features:
£
Low Drive Power
£
Low V
CE(sat)
£
Super-Fast Recovery
Free-Wheel Diode
£
Isolated Baseplate for Easy
Heat Sinking
Applications:
£
Traction
£
Medium Voltage Drives
£
High Voltage Power Supplies
Ordering Information:
Example: Select the complete
part module number you desire
from the table below -i.e.
CM600HG-130H is a 6500V
(V
CES
), 600 Ampere Single
IGBTMOD™ Power Module.
Type
Current Rating
V
CES
Amperes
Volts (x 50)
CM
600
130
Dimensions
Inches
Millimeters
J
2.33
59.2
K
2.41
61.2
L
1.61
41.0
M
0.71
18.0
N
1.50
38.0
P
0.20
5.0
Q
0.28 Dia.
7.0 Dia.
