Document Number: 94564 For technical questions, contact: [email protected] www.vishay.com
Revision: 05-May-08 5
UFB60FA60P
Insulated Ultrafast
Rectifier Module, 60 A
Vishay High Power Products
Fig. 9 - Typical Stored Current vs. dI
F
/dt
Fig. 10 - Reverse Recovery Parameter Test Circuit
0 0 0 1 0 0 1
0
5
10
15
20
25
30
If = 30A, 125°C
If = 30A, 25°C
Vr = 200V
I rr
(A)
dI
F
/dt (A/μs )
IRFP250
D.U.T.
L = 70 µH
V
R
= 200 V
0.01 Ω
G
D
S
dI
F
/dt
adjust
