www.vishay.com For technical questions, contact: [email protected] Document Number: 94564
2 Revision: 05-May-08
UFB60FA60P
Vishay High Power Products Insulated Ultrafast
Rectifier Module, 60 A
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode breakdown voltage V
BR
I
R
= 100 µA 600 - -
V
Forward voltage V
FM
I
F
= 30 A - 1.32 1.69
I
F
= 60 A - 1.52 1.9
I
F
= 30 A
T
J
= 125 °C
- 1.14 1.39
I
F
= 60 A - 1.38 1.66
Reverse leakage current I
RM
V
R
= V
R
rated - 0.1 100 µA
T
J
= 175 °C, V
R
= V
R
rated - 0.2 1.0 mA
Junction capacitance C
T
V
R
= 600 V - 50 - pF
DYNAMIC RECOVERY CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
T
J
= 25 °C
I
F
= 30 A
dI
F
/dt = 200 A/µs
V
R
= 200 V
- 79 118
ns
T
J
= 125 °C - 155 209
Peak recovery current I
RRM
T
J
= 25 °C - 6 10
A
T
J
= 125 °C - 14 20
Reverse recovery charge Q
rr
T
J
= 25 °C - 234 590
nC
T
J
= 125 °C - 1085 2090
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Junction to case,
single leg conducting
R
thJC
- - 1.5
°C/W Junction to case,
both leg conducting
- - 0.75
Case to heatsink R
thCS
Flat, greased surface - 0.05 -
Weight - 30 - g
Mounting torque - 1.3 - N · m
