RW
Vitreous Wirewound Resistors Vishay Draloric
Document Number: 21005 For technical questions contact [email protected] www.vishay.com
Revision: 04-Jul-06 91
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: RW0104411009JLX000 (preferred part number format)
MODEL SIZE
SPECIAL
CHARACTER
VALUE TOLERANCE PACKING SPECIAL
RW 01044 = 10/44
01225 = 12/25
01238 = 12/38
01251 = 12/51
01276 = 12/76
02076 = 20/76
20102 = 20/102
30102 = 30/102
30152 = 30/152
30203 = 30/203
30267 = 30/267
30305 = 30/305
00029 = 29
00030 = 30
00031 = 31
00032 = 32
00033 = 33
00035 = 35
00036 = 36
00037 = 37
00038 = 38
00047 = 47
0 = neutral
1 = E
2 = NI
7 = FST
C = E FST
H = NI FST
Z = value
overflow (BV)
(Note: NI is
also known
as SWI)
3 digit value
1 digit multiplier
Multiplier:
7 = *10 -3
8 = *10 -2
9 = *10 -1
0 = *10 0
1 = *10 1
2 = *10 2
3 = *10 3
4 = *10 4
J = ± 5.0 %
K = ± 10.0 %
(see
Packing table)
The 5 digit BV number will be
encoded using a 36 character
code. This code contains
numbers 0...9 and letters A...Z
(36 characters total) and allows
to encode at least 46 655 five
digit BV numbers.
000 = standard
Historical Part Number example: RW 10 x 44 E 10R 5 % (will continue to be accepted)
RW 10 x 44 E 10R 5 %
HISTORICAL MODEL SPECIAL CHARACTER VALUE TOLERANCE
PACKING TABLE
SAP DESCRIPTION TYPE
LX Loose pack, without quantity all
ZX Special pack (with BV #), without quantity all
Note: LX = B29 on Dale legacy
ZX = S51 on Dale legacy
1 0 4 4 1 0 0 1 W 0 J L X 0 9 R 0 0
