RW
Vitreous Wirewound Resistors
Vishay Draloric
Document Number: 21005
For technical questions contact [email protected]
www.vishay.com
Revision: 04-Jul-06
89
Note
1. Values in the first line of 10 % tolerance are produced with corrugated ribbon.
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
POWER RATING
P
40 °C
W
LIMITING VOLTAGE
V
RESISTANCE
RANGE
1)
Ω
TOLERANCE
± %
E-SERIES
RW 12/76
45
1000
2R0 - 7R5
10
E 12
8R2 - 91K
10
E 12
8R2 - 91K
5
E 24
RW 12/76 E
27
2R0 - 12R
10
E 12
13R - 4K3
10
E 12
13R - 4K3
5
E 24
RW 12/76 Ni
27
16R - 6K2
10
E 12
16R - 6K2
5
E 24
RW 20/76
70
1000
1R0 - 11R
10
E 12
12R - 75K
10
E 12
12R - 75K
5
E 24
RW 20/76 E
42
1R0 - 18R
10
E 12
20R - 6K8
10
E 12
20R - 6K8
5
E 24
RW 20/76 Ni
42
1000
24R - 10K
10
E 12
24R - 10K
5
E 24
RW 20/102
90
1400
3R - 16R
10
E 12
18R - 110K
10
E 12
18R - 110K
5
E 24
RW 20/102 E
55
3R - 27R
10
E 12
30R - 10K
10
E 12
30R - 10K
5
E 24
RW 20/102 Ni
55
36R - 15K
10
E 12
36R - 15K
5
E 24
RW 30/102
130
1600
2R7 - 22R
10
E 12
24R - 160K
10
E 12
24R - 160K
5
E 24
RW 30/102 E
80
2R7 - 22R
10
E 12
43R - 15K
10
E 12
43R - 15K
5
E 24
RW 30/152
220
2500
4R7 - 30R
10
E 12
33R - 200K
10
E 12
33R - 200K
5
E 24
RW 30/152 E
130
4R7 - 30R
10
E 12
75R - 24K
10
E 12
75R - 24K
5
E 24
